「DUBBO系列」线程模型实现原理

JAVA前线 2020-06-01

192

IT徐胖子原创本文未授权请勿转载

1 线程模型概念

DUBBO默认网络通信采用Netty框架，Netty服务端通常包含两个线程组：bossGroup线程组和workerGroup线程组。

bossGroup线程组只有一个线程处理客户端连接请求，连接完成后将完成三次握手的SocketChannel连接分发给workerGroup处理读写请求，这两个线程组被称为IO线程。我们编写一个Netty服务端进行观察。

public class NettyServer {
    public static void main(String[] args) throws Exception {
        EventLoopGroup bossGroup = new NioEventLoopGroup(1);
        EventLoopGroup workerGroup = new NioEventLoopGroup(8);
        try {
            ServerBootstrap bootstrap = new ServerBootstrap();
            bootstrap.group(bossGroup, workerGroup)
            .channel(NioServerSocketChannel.class)
            .option(ChannelOption.SO_BACKLOG, 128)
            .childOption(ChannelOption.SO_KEEPALIVE, true)
            .childHandler(new ChannelInitializer<SocketChannel>() {
                @Override
                protected void initChannel(SocketChannel ch) throws Exception {
                    ch.pipeline().addLast(new NettyServerHandler());
                }
            });
            ChannelFuture channelFuture = bootstrap.bind(9999).sync();
            System.out.println("服务端准备就绪");
            channelFuture.channel().closeFuture().sync();
        } catch (Exception ex) {
            System.out.println(ex.getMessage());
        } finally {
            bossGroup.shutdownGracefully();
            workerGroup.shutdownGracefully();
        }
    }
}

我们再引出另一个概念：业务线程。服务生产者接收到请求后，如果处理逻辑可以快速处理完成，并且不会发起新IO请求，那么可以直接放在IO线程处理，减少线程池调度与上下文切换提高效率。

服务生产者接收到请求后，如果处理逻辑非常耗时，或者会发起新IO请求例如查询数据库，那么必须派发到业务线程池处理。

DUBBO提供了多种线程模型，选择线程模型需要在配置文件指定dispatcher属性

<dubbo:protocol name="dubbo" dispatcher="all" >
<dubbo:protocol name="dubbo" dispatcher="direct" >
<dubbo:protocol name="dubbo" dispatcher="message" >
<dubbo:protocol name="dubbo" dispatcher="execution" >
<dubbo:protocol name="dubbo" dispatcher="connection" >

不同线程模型在不同场景选择使用IO线程还是业务线程，参看DUBBO官网文档

all
所有消息都派发到业务线程池，包括请求，响应，连接事件，断开事件，心跳


direct
所有消息都不派发到业务线程池，全部在IO线程直接执行


message
只有请求响应消息派发到业务线程池，其它连接断开事件，心跳等消息直接在IO线程执行


execution
只有请求消息派发到业务线程池，响应和其它连接断开事件，心跳等消息直接在IO线程执行


connection
在IO线程上将连接断开事件放入队列，有序逐个执行，其它消息派发到业务线程池

2 线程模型确定时机

生产者在暴露服务时确认线程模型，消费者在发起连接时确认线程模型，默认线程模型AllDispatcher，本文以生产者为例

public class NettyTransporter implements Transporter {
    @Override
    public Server bind(URL url, ChannelHandler listener) throws RemotingException {
        // 生产者暴露服务
        return new NettyServer(url, listener);
    }

    @Override
    public Client connect(URL url, ChannelHandler listener) throws RemotingException {
        // 消费者发起连接
        return new NettyClient(url, listener);
    }
}


public class NettyServer extends AbstractServer implements Server {
    public NettyServer(URL url, ChannelHandler handler) throws RemotingException {
        // 默认线程模型all
        // MultiMessageHandler(HeartbeatHandler(AllChannelHandler))
        super(url, ChannelHandlers.wrap(handler, ExecutorUtil.setThreadName(url, SERVER_THREAD_POOL_NAME)));
    }
}

ChannelHandlers.wrap方法获取Dispatcher自适应扩展点，如果配置指定dispatcher属性，扩展点加载器会从URL获取属性值加载对应线程模型

public class ChannelHandlers {
    protected ChannelHandler wrapInternal(ChannelHandler handler, URL url) {
        // Dispatcher默认自适应扩展点AllDispatcher
        return new MultiMessageHandler(new HeartbeatHandler(ExtensionLoader.getExtensionLoader(Dispatcher.class).getAdaptiveExtension().dispatch(handler, url)));
    }
}


@SPI(AllDispatcher.NAME)
public interface Dispatcher {
    @Adaptive({Constants.DISPATCHER_KEY, "channel.handler"})
    ChannelHandler dispatch(ChannelHandler handler, URL url);
}

3 源码分析

3.1 All

public class AllDispatcher implements Dispatcher {


    // 线程模型名称
    public static final String NAME = "all";


    // 具体实现策略
    @Override
    public ChannelHandler dispatch(ChannelHandler handler, URL url) {
        return new AllChannelHandler(handler, url);
    }
}


public class AllChannelHandler extends WrappedChannelHandler {


    @Override
    public void connected(Channel channel) throws RemotingException {
        // 连接完成事件交给业务线程池
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.CONNECTED));
        } catch (Throwable t) {
            throw new ExecutionException("connect event", channel, getClass() + " error when process connected event", t);
        }
    }


    @Override
    public void disconnected(Channel channel) throws RemotingException {
        // 断开连接事件交给业务线程池
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.DISCONNECTED));
        } catch (Throwable t) {
            throw new ExecutionException("disconnect event", channel, getClass() + " error when process disconnected event", t);
        }
    }


    @Override
    public void received(Channel channel, Object message) throws RemotingException {
        // 请求响应事件交给业务线程池
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.RECEIVED, message));
        } catch (Throwable t) {
            if(message instanceof Request && t instanceof RejectedExecutionException) {
                Request request = (Request)message;
                if(request.isTwoWay()) {
                    String msg = "Server side(" + url.getIp() + "," + url.getPort() + ") threadpool is exhausted ,detail msg:" + t.getMessage();
                    Response response = new Response(request.getId(), request.getVersion());
                    response.setStatus(Response.SERVER_THREADPOOL_EXHAUSTED_ERROR);
                    response.setErrorMessage(msg);
                    channel.send(response);
                    return;
                }
            }
            throw new ExecutionException(message, channel, getClass() + " error when process received event", t);
        }
    }


    @Override
    public void caught(Channel channel, Throwable exception) throws RemotingException {
        // 异常事件交给业务线程池
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.CAUGHT, exception));
        } catch (Throwable t) {
            throw new ExecutionException("caught event", channel, getClass() + " error when process caught event", t);
        }
    }
}

3.2 Direct

public class DirectDispatcher implements Dispatcher {


    // 线程模型名称
    public static final String NAME = "direct";


    // 具体实现策略
    @Override
    public ChannelHandler dispatch(ChannelHandler handler, URL url) {
        // 直接返回handler表示所有事件交给IO线程处理
        return handler;
    }
}

3.3 Message

public class MessageOnlyDispatcher implements Dispatcher {


    // 线程模型名称
    public static final String NAME = "message";


    // 具体实现策略
    @Override
    public ChannelHandler dispatch(ChannelHandler handler, URL url) {
        return new MessageOnlyChannelHandler(handler, url);
    }
}


public class MessageOnlyChannelHandler extends WrappedChannelHandler {


    @Override
    public void received(Channel channel, Object message) throws RemotingException {
        // 请求响应事件交给业务线程池处理
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.RECEIVED, message));
        } catch (Throwable t) {
            throw new ExecutionException(message, channel, getClass() + " error when process received event .", t);
        }
    }
}

3.4 Execution

public class ExecutionDispatcher implements Dispatcher {


    // 线程模型名称
    public static final String NAME = "execution";


    // 具体实现策略
    @Override
    public ChannelHandler dispatch(ChannelHandler handler, URL url) {
        return new ExecutionChannelHandler(handler, url);
    }
}


public class ExecutionChannelHandler extends WrappedChannelHandler {


    @Override
    public void received(Channel channel, Object message) throws RemotingException {


        // 获取业务线程池
        ExecutorService cexecutor = getExecutorService();


        // 请求类消息交给业务线程池处理
        if (message instanceof Request) {
            try {
                cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.RECEIVED, message));
            } catch (Throwable t) {
                if (t instanceof RejectedExecutionException) {
                    Request request = (Request) message;
                    if (request.isTwoWay()) {
                        String msg = "Server side(" + url.getIp() + "," + url.getPort() + ") thread pool is exhausted, detail msg:" + t.getMessage();
                        Response response = new Response(request.getId(), request.getVersion());
                        response.setStatus(Response.SERVER_THREADPOOL_EXHAUSTED_ERROR);
                        response.setErrorMessage(msg);
                        channel.send(response);
                        return;
                    }
                }
                throw new ExecutionException(message, channel, getClass() + " error when process received event.", t);
            }
        } else {
            handler.received(channel, message);
        }
    }
}

3.5 Connection

public class ConnectionOrderedDispatcher implements Dispatcher {


    // 线程模型名称
    public static final String NAME = "connection";


    // 具体实现策略
    @Override
    public ChannelHandler dispatch(ChannelHandler handler, URL url) {
        return new ConnectionOrderedChannelHandler(handler, url);
    }
}


public class ConnectionOrderedChannelHandler extends WrappedChannelHandler {
    protected final ThreadPoolExecutor connectionExecutor;
    private final int queuewarninglimit;


    public ConnectionOrderedChannelHandler(ChannelHandler handler, URL url) {
        super(handler, url);


        // 构造函数声明只有一个线程的线程池进行串行化处理
        String threadName = url.getParameter(Constants.THREAD_NAME_KEY, Constants.DEFAULT_THREAD_NAME);
        connectionExecutor = new ThreadPoolExecutor(1, 1,
                0L, TimeUnit.MILLISECONDS,
                new LinkedBlockingQueue<Runnable>(url.getPositiveParameter(Constants.CONNECT_QUEUE_CAPACITY, Integer.MAX_VALUE)),
                new NamedThreadFactory(threadName, true),
                new AbortPolicyWithReport(threadName, url)
                                                   );
        queuewarninglimit = url.getParameter(Constants.CONNECT_QUEUE_WARNING_SIZE, Constants.DEFAULT_CONNECT_QUEUE_WARNING_SIZE);
    }


    @Override
    public void connected(Channel channel) throws RemotingException {
        try {
            // 检查线程池队列元素个数
            checkQueueLength();
            // 连接完成事件交给线程池处理
            connectionExecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.CONNECTED));
        } catch (Throwable t) {
            throw new ExecutionException("connect event", channel, getClass() + " error when process connected event .", t);
        }
    }


    @Override
    public void disconnected(Channel channel) throws RemotingException {
        try {
            // 检查线程池队列元素个数
            checkQueueLength();
            // 连接断开事件交给线程池处理
            connectionExecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.DISCONNECTED));
        } catch (Throwable t) {
            throw new ExecutionException("disconnected event", channel, getClass() + " error when process disconnected event .", t);
        }
    }


    @Override
    public void received(Channel channel, Object message) throws RemotingException {
        // 请求响应事件交给业务线程池处理
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.RECEIVED, message));
        } catch (Throwable t) {
            if (message instanceof Request && t instanceof RejectedExecutionException) {
                Request request = (Request) message;
                if (request.isTwoWay()) {
                    String msg = "Server side(" + url.getIp() + "," + url.getPort() + ") threadpool is exhausted ,detail msg:" + t.getMessage();
                    Response response = new Response(request.getId(), request.getVersion());
                    response.setStatus(Response.SERVER_THREADPOOL_EXHAUSTED_ERROR);
                    response.setErrorMessage(msg);
                    channel.send(response);
                    return;
                }
            }
            throw new ExecutionException(message, channel, getClass() + " error when process received event .", t);
        }
    }


    @Override
    public void caught(Channel channel, Throwable exception) throws RemotingException {
        // 异常事件交给业务线程池处理
        ExecutorService cexecutor = getExecutorService();
        try {
            cexecutor.execute(new ChannelEventRunnable(channel, handler, ChannelState.CAUGHT, exception));
        } catch (Throwable t) {
            throw new ExecutionException("caught event", channel, getClass() + " error when process caught event .", t);
        }
    }


    // 检查队列大小
    private void checkQueueLength() {
        if (connectionExecutor.getQueue().size() > queuewarninglimit) {
            logger.warn(new IllegalThreadStateException("connectionordered channel handler `queue size: " + connectionExecutor.getQueue().size() + " exceed the warning limit number :" + queuewarninglimit));
        }
    }
}

4 文章总结

本文分析了DUBBO线程模型源码，可以根据不同业务场景选择不同线程模型。后续文章分析DUBBO线程池策略请继续关注。
