RocketMQ源码分析之消息消费队列

徘徊笔记 2019-04-23

189

来源：https://github.com/apache/rocketmq

ConsumeQueue：消息消费队列，引入的目的主要是提高消息消费的性能，由于RocketMQ是基于主题topic的订阅模式，消息消费是针对主题进行的，如果要遍历commitlog文件中根据topic检索消息是非常低效的。Consumer即可根据ConsumeQueue来查找待消费的消息。其中，ConsumeQueue（逻辑消费队列）作为消费消息的索引，保存了指定Topic下的队列消息在CommitLog中的起始物理偏移量offset，消息大小size和消息Tag的HashCode值。consumequeue文件可以看成是基于topic的commitlog索引文件，故consumequeue文件夹的组织方式如下：topic/queue/file三层组织结构，具体存储路径为：$HOME/store/consumequeue/{topic}/{queueId}/{fileName}。同样consumequeue文件采取定长设计，每一个条目共20个字节，分别为8字节的commitlog物理偏移量、4字节的消息长度、8字节tag hashcode，单个文件由30W个条目组成，可以像数组一样随机访问每一个条目，每个ConsumeQueue文件大小约5.72M；

ReputMessageService

主要作用是获取消息然后构建消息消费队列索引，以及根据key条件查询索引，消息消费过滤服务类。该线程在初始化完成后就开始启动了，reputFromOffset默认值为0，也就是从头开始，当然在开始启动时会默认给他设置目前消息文件的最大偏移量

，也就是不重复构建索引等文件。根据初始偏移量开始查找消息，有消息的话就开始循环读取，每一次只读取一个消息。

private void doReput() {
    for (boolean doNext = true; this.isCommitLogAvailable() && doNext; ) {


        if (DefaultMessageStore.this.getMessageStoreConfig().isDuplicationEnable()
            && this.reputFromOffset >= DefaultMessageStore.this.getConfirmOffset()) {
            break;
        }


        SelectMappedBufferResult result = DefaultMessageStore.this.commitLog.getData(reputFromOffset);
        if (result != null) {
            try {
                this.reputFromOffset = result.getStartOffset();


                for (int readSize = 0; readSize < result.getSize() && doNext; ) {
                    DispatchRequest dispatchRequest =
                        DefaultMessageStore.this.commitLog.checkMessageAndReturnSize(result.getByteBuffer(), false, false);
                    int size = dispatchRequest.getMsgSize();


                    if (dispatchRequest.isSuccess()) {
                        if (size > 0) {
                            DefaultMessageStore.this.doDispatch(dispatchRequest);


                            if (BrokerRole.SLAVE != DefaultMessageStore.this.getMessageStoreConfig().getBrokerRole()
                                && DefaultMessageStore.this.brokerConfig.isLongPollingEnable()) {
                                DefaultMessageStore.this.messageArrivingListener.arriving(dispatchRequest.getTopic(),
                                    dispatchRequest.getQueueId(), dispatchRequest.getConsumeQueueOffset() + 1,
                                    dispatchRequest.getTagsCode(), dispatchRequest.getStoreTimestamp(),
                                    dispatchRequest.getBitMap(), dispatchRequest.getPropertiesMap());
                            }


                            this.reputFromOffset += size;
                            readSize += size;
                            if (DefaultMessageStore.this.getMessageStoreConfig().getBrokerRole() == BrokerRole.SLAVE) {
                                DefaultMessageStore.this.storeStatsService
                                    .getSinglePutMessageTopicTimesTotal(dispatchRequest.getTopic()).incrementAndGet();
                                DefaultMessageStore.this.storeStatsService
                                    .getSinglePutMessageTopicSizeTotal(dispatchRequest.getTopic())
                                    .addAndGet(dispatchRequest.getMsgSize());
                            }
                        } else if (size == 0) {
                            this.reputFromOffset = DefaultMessageStore.this.commitLog.rollNextFile(this.reputFromOffset);
                            readSize = result.getSize();
                        }
                    } else if (!dispatchRequest.isSuccess()) {


                        if (size > 0) {
                            log.error("[BUG]read total count not equals msg total size. reputFromOffset={}", reputFromOffset);
                            this.reputFromOffset += size;
                        } else {
                            doNext = false;
                            if (DefaultMessageStore.this.brokerConfig.getBrokerId() == MixAll.MASTER_ID) {
                                log.error("[BUG]the master dispatch message to consume queue error, COMMITLOG OFFSET: {}",
                                    this.reputFromOffset);


                                this.reputFromOffset += result.getSize() - readSize;
                            }
                        }
                    }
                }
            } finally {
                result.release();
            }
        } else {
            doNext = false;
        }
    }
}


@Override
public void run() {
    DefaultMessageStore.log.info(this.getServiceName() + " service started");


    while (!this.isStopped()) {
        try {
            Thread.sleep(1);
            this.doReput();
        } catch (Exception e) {
            DefaultMessageStore.log.warn(this.getServiceName() + " service has exception. ", e);
        }
    }


    DefaultMessageStore.log.info(this.getServiceName() + " service end");
}
复制

检查消息是否合法最后返回消息各个属性，不需要返回消息体。当文件结尾或者消息正确时返回true，前者size为0，后者大于0，非法的消息返回-1和不正确

public DispatchRequest checkMessageAndReturnSize(java.nio.ByteBuffer byteBuffer, final boolean checkCRC,
    final boolean readBody) {
    try {
        // 1 TOTAL SIZE
        int totalSize = byteBuffer.getInt();


        // 2 MAGIC CODE
        int magicCode = byteBuffer.getInt();
        switch (magicCode) {
            case MESSAGE_MAGIC_CODE:
                break;
            case BLANK_MAGIC_CODE:
                return new DispatchRequest(0, true /* success */);
            default:
                log.warn("found a illegal magic code 0x" + Integer.toHexString(magicCode));
                return new DispatchRequest(-1, false /* success */);
        }


        byte[] bytesContent = new byte[totalSize];


        int bodyCRC = byteBuffer.getInt();


        int queueId = byteBuffer.getInt();


        int flag = byteBuffer.getInt();


        long queueOffset = byteBuffer.getLong();


        long physicOffset = byteBuffer.getLong();


        int sysFlag = byteBuffer.getInt();


        long bornTimeStamp = byteBuffer.getLong();


        ByteBuffer byteBuffer1 = byteBuffer.get(bytesContent, 0, 8);


        long storeTimestamp = byteBuffer.getLong();


        ByteBuffer byteBuffer2 = byteBuffer.get(bytesContent, 0, 8);


        int reconsumeTimes = byteBuffer.getInt();


        long preparedTransactionOffset = byteBuffer.getLong();


        int bodyLen = byteBuffer.getInt();
        if (bodyLen > 0) {
            if (readBody) {
                byteBuffer.get(bytesContent, 0, bodyLen);


                if (checkCRC) {
                    int crc = UtilAll.crc32(bytesContent, 0, bodyLen);
                    if (crc != bodyCRC) {
                        log.warn("CRC check failed. bodyCRC={}, currentCRC={}", crc, bodyCRC);
                        return new DispatchRequest(-1, false/* success */);
                    }
                }
            } else {
                byteBuffer.position(byteBuffer.position() + bodyLen);
            }
        }


        byte topicLen = byteBuffer.get();
        byteBuffer.get(bytesContent, 0, topicLen);
        String topic = new String(bytesContent, 0, topicLen, MessageDecoder.CHARSET_UTF8);


        long tagsCode = 0;
        String keys = "";
        String uniqKey = null;


        short propertiesLength = byteBuffer.getShort();
        Map<String, String> propertiesMap = null;
        if (propertiesLength > 0) {
            byteBuffer.get(bytesContent, 0, propertiesLength);
            String properties = new String(bytesContent, 0, propertiesLength, MessageDecoder.CHARSET_UTF8);
            propertiesMap = MessageDecoder.string2messageProperties(properties);


            keys = propertiesMap.get(MessageConst.PROPERTY_KEYS);


            uniqKey = propertiesMap.get(MessageConst.PROPERTY_UNIQ_CLIENT_MESSAGE_ID_KEYIDX);


            String tags = propertiesMap.get(MessageConst.PROPERTY_TAGS);
            if (tags != null && tags.length() > 0) {
                tagsCode = MessageExtBrokerInner.tagsString2tagsCode(MessageExt.parseTopicFilterType(sysFlag), tags);
            }


            // Timing message processing
            {
                String t = propertiesMap.get(MessageConst.PROPERTY_DELAY_TIME_LEVEL);
                if (ScheduleMessageService.SCHEDULE_TOPIC.equals(topic) && t != null) {
                    int delayLevel = Integer.parseInt(t);


                    if (delayLevel > this.defaultMessageStore.getScheduleMessageService().getMaxDelayLevel()) {
                        delayLevel = this.defaultMessageStore.getScheduleMessageService().getMaxDelayLevel();
                    }


                    if (delayLevel > 0) {
                        tagsCode = this.defaultMessageStore.getScheduleMessageService().computeDeliverTimestamp(delayLevel,
                            storeTimestamp);
                    }
                }
            }
        }


        int readLength = calMsgLength(bodyLen, topicLen, propertiesLength);
        if (totalSize != readLength) {
            doNothingForDeadCode(reconsumeTimes);
            doNothingForDeadCode(flag);
            doNothingForDeadCode(bornTimeStamp);
            doNothingForDeadCode(byteBuffer1);
            doNothingForDeadCode(byteBuffer2);
            log.error(
                "[BUG]read total count not equals msg total size. totalSize={}, readTotalCount={}, bodyLen={}, topicLen={}, propertiesLength={}",
                totalSize, readLength, bodyLen, topicLen, propertiesLength);
            return new DispatchRequest(totalSize, false/* success */);
        }


        return new DispatchRequest(
            topic,
            queueId,
            physicOffset,
            totalSize,
            tagsCode,
            storeTimestamp,
            queueOffset,
            keys,
            uniqKey,
            sysFlag,
            preparedTransactionOffset,
            propertiesMap
        );
    } catch (Exception e) {
    }


    return new DispatchRequest(-1, false /* success */);
}
复制

如果消息解析不成功的话就打印日志，成功且消息长度等于0，就把偏移量移到下一个文件的开始下标，下一次继续读取消息

public long rollNextFile(final long offset) {
    int mappedFileSize = this.defaultMessageStore.getMessageStoreConfig().getMapedFileSizeCommitLog();
    return offset + mappedFileSize - offset % mappedFileSize;
}
复制

成功且消息长度大于0的话，判断当前是否是主节点并且是否支持长轮训，支持的话就直接通知拉取请求，否则的话就只能等待定时时间完成，然后开始构建消息队列，当该消息是普通消息或者是事务消息的最终确认状态的话就开始构建。

public void doDispatch(DispatchRequest req) {
    for (CommitLogDispatcher dispatcher : this.dispatcherList) {
        dispatcher.dispatch(req);
    }
}


class CommitLogDispatcherBuildConsumeQueue implements CommitLogDispatcher {


    @Override
    public void dispatch(DispatchRequest request) {
        final int tranType = MessageSysFlag.getTransactionValue(request.getSysFlag());
        switch (tranType) {
            case MessageSysFlag.TRANSACTION_NOT_TYPE:
            case MessageSysFlag.TRANSACTION_COMMIT_TYPE:
                DefaultMessageStore.this.putMessagePositionInfo(request);
                break;
            case MessageSysFlag.TRANSACTION_PREPARED_TYPE:
            case MessageSysFlag.TRANSACTION_ROLLBACK_TYPE:
                break;
        }
    }
}


public void putMessagePositionInfo(DispatchRequest dispatchRequest) {
    ConsumeQueue cq = this.findConsumeQueue(dispatchRequest.getTopic(), dispatchRequest.getQueueId());
    cq.putMessagePositionInfoWrapper(dispatchRequest);
}
复制

查找消费队列是否存在，不存在则创建新的。

ConcurrentMap<String/* topic */, ConcurrentMap<Integer/* queueId */, ConsumeQueue>> consumeQueueTable;


public ConsumeQueue findConsumeQueue(String topic, int queueId) {
    ConcurrentMap<Integer, ConsumeQueue> map = consumeQueueTable.get(topic);
    if (null == map) {
        ConcurrentMap<Integer, ConsumeQueue> newMap = new ConcurrentHashMap<Integer, ConsumeQueue>(128);
        ConcurrentMap<Integer, ConsumeQueue> oldMap = consumeQueueTable.putIfAbsent(topic, newMap);
        if (oldMap != null) {
            map = oldMap;
        } else {
            map = newMap;
        }
    }


    ConsumeQueue logic = map.get(queueId);
    if (null == logic) {
        ConsumeQueue newLogic = new ConsumeQueue(
            topic,
            queueId,
            StorePathConfigHelper.getStorePathConsumeQueue(this.messageStoreConfig.getStorePathRootDir()),
            this.getMessageStoreConfig().getMapedFileSizeConsumeQueue(),
            this);
        ConsumeQueue oldLogic = map.putIfAbsent(queueId, newLogic);
        if (oldLogic != null) {
            logic = oldLogic;
        } else {
            logic = newLogic;
        }
    }


    return logic;
}
复制

创建新的消费队列文件，和消息存储文件类似，

public ConsumeQueue(
    final String topic,
    final int queueId,
    final String storePath,
    final int mappedFileSize,
    final DefaultMessageStore defaultMessageStore) {
    this.storePath = storePath;
    this.mappedFileSize = mappedFileSize;
    this.defaultMessageStore = defaultMessageStore;


    this.topic = topic;
    this.queueId = queueId;


    String queueDir = this.storePath
        + File.separator + topic
        + File.separator + queueId;


    this.mappedFileQueue = new MappedFileQueue(queueDir, mappedFileSize, null);


    this.byteBufferIndex = ByteBuffer.allocate(CQ_STORE_UNIT_SIZE);


    if (defaultMessageStore.getMessageStoreConfig().isEnableConsumeQueueExt()) {
        this.consumeQueueExt = new ConsumeQueueExt(
            topic,
            queueId,
            StorePathConfigHelper.getStorePathConsumeQueueExt(defaultMessageStore.getMessageStoreConfig().getStorePathRootDir()),
            defaultMessageStore.getMessageStoreConfig().getMappedFileSizeConsumeQueueExt(),
            defaultMessageStore.getMessageStoreConfig().getBitMapLengthConsumeQueueExt()
        );
    }
}
复制

开始构建消息索引，判断现在磁盘是否可写，判断是否要保存消费队列额外信息，也就是关于消息消费过滤的布隆过滤器的BitMap。

public void putMessagePositionInfoWrapper(DispatchRequest request) {
    final int maxRetries = 30;
    boolean canWrite = this.defaultMessageStore.getRunningFlags().isCQWriteable();
    for (int i = 0; i < maxRetries && canWrite; i++) {
        long tagsCode = request.getTagsCode();
        if (isExtWriteEnable()) {
            ConsumeQueueExt.CqExtUnit cqExtUnit = new ConsumeQueueExt.CqExtUnit();
            cqExtUnit.setFilterBitMap(request.getBitMap());
            cqExtUnit.setMsgStoreTime(request.getStoreTimestamp());
            cqExtUnit.setTagsCode(request.getTagsCode());


            long extAddr = this.consumeQueueExt.put(cqExtUnit);
            if (isExtAddr(extAddr)) {
                tagsCode = extAddr;
            } else {
                log.warn("Save consume queue extend fail, So just save tagsCode! {}, topic:{}, queueId:{}, offset:{}", cqExtUnit,
                    topic, queueId, request.getCommitLogOffset());
            }
        }
        boolean result = this.putMessagePositionInfo(request.getCommitLogOffset(),
            request.getMsgSize(), tagsCode, request.getConsumeQueueOffset());
        if (result) {
            this.defaultMessageStore.getStoreCheckpoint().setLogicsMsgTimestamp(request.getStoreTimestamp());
            return;
        } else {
            // XXX: warn and notify me
            log.warn("[BUG]put commit log position info to " + topic + ":" + queueId + " " + request.getCommitLogOffset()
                + " failed, retry " + i + " times");


            try {
                Thread.sleep(1000);
            } catch (InterruptedException e) {
                log.warn("", e);
            }
        }
    }


    // XXX: warn and notify me
    log.error("[BUG]consume queue can not write, {} {}", this.topic, this.queueId);
    this.defaultMessageStore.getRunningFlags().makeLogicsQueueError();
}


//for consume queue, just ignore the DISK_FULL_BIT
public boolean isCQWriteable() {
    if ((this.flagBits & (NOT_WRITEABLE_BIT | WRITE_LOGICS_QUEUE_ERROR_BIT | WRITE_INDEX_FILE_ERROR_BIT)) == 0) {
        return true;
    }


    return false;
}
复制

把索引信息写入文件，包括消息存储偏移量，消息大小，tags的hashCode以及在该topic该队列中所处的下标，每个索引信息由20个字节组成，然后开始找对应的文件

private boolean putMessagePositionInfo(final long offset, final int size, final long tagsCode,
    final long cqOffset) {


    if (offset <= this.maxPhysicOffset) {
        return true;
    }


    this.byteBufferIndex.flip();
    this.byteBufferIndex.limit(CQ_STORE_UNIT_SIZE);
    this.byteBufferIndex.putLong(offset);
    this.byteBufferIndex.putInt(size);
    this.byteBufferIndex.putLong(tagsCode);


    final long expectLogicOffset = cqOffset * CQ_STORE_UNIT_SIZE;


    MappedFile mappedFile = this.mappedFileQueue.getLastMappedFile(expectLogicOffset);
    if (mappedFile != null) {


        if (mappedFile.isFirstCreateInQueue() && cqOffset != 0 && mappedFile.getWrotePosition() == 0) {
            this.minLogicOffset = expectLogicOffset;
            this.mappedFileQueue.setFlushedWhere(expectLogicOffset);
            this.mappedFileQueue.setCommittedWhere(expectLogicOffset);
            this.fillPreBlank(mappedFile, expectLogicOffset);
            log.info("fill pre blank space " + mappedFile.getFileName() + " " + expectLogicOffset + " "
                + mappedFile.getWrotePosition());
        }


        if (cqOffset != 0) {
            long currentLogicOffset = mappedFile.getWrotePosition() + mappedFile.getFileFromOffset();


            if (expectLogicOffset < currentLogicOffset) {
                log.warn("Build  consume queue repeatedly, expectLogicOffset: {} currentLogicOffset: {} Topic: {} QID: {} Diff: {}",
                    expectLogicOffset, currentLogicOffset, this.topic, this.queueId, expectLogicOffset - currentLogicOffset);
                return true;
            }


            if (expectLogicOffset != currentLogicOffset) {
                LOG_ERROR.warn(
                    "[BUG]logic queue order maybe wrong, expectLogicOffset: {} currentLogicOffset: {} Topic: {} QID: {} Diff: {}",
                    expectLogicOffset,
                    currentLogicOffset,
                    this.topic,
                    this.queueId,
                    expectLogicOffset - currentLogicOffset
                );
            }
        }
        this.maxPhysicOffset = offset;
        return mappedFile.appendMessage(this.byteBufferIndex.array());
    }
    return false;
}
复制

如果这是消息消费队列的第一个文件并且写下标为0但是消息所处的队列下标不为0的话，就要填充之前空白的部分，最后判断期待的消息偏移量是否与实际的偏移量相对应，否则的话打印日志。

private void fillPreBlank(final MappedFile mappedFile, final long untilWhere) {
    ByteBuffer byteBuffer = ByteBuffer.allocate(CQ_STORE_UNIT_SIZE);
    byteBuffer.putLong(0L);
    byteBuffer.putInt(Integer.MAX_VALUE);
    byteBuffer.putLong(0L);


    int until = (int) (untilWhere % this.mappedFileQueue.getMappedFileSize());
    for (int i = 0; i < until; i += CQ_STORE_UNIT_SIZE) {
        mappedFile.appendMessage(byteBuffer.array());
    }
}
复制

开始把数据写入文件。

public boolean appendMessage(final byte[] data) {
  int currentPos = this.wrotePosition.get();


  if ((currentPos + data.length) <= this.fileSize) {
      try {
          this.fileChannel.position(currentPos);
          this.fileChannel.write(ByteBuffer.wrap(data));
      } catch (Throwable e) {
          log.error("Error occurred when append message to mappedFile.", e);
      }
      this.wrotePosition.addAndGet(data.length);
      return true;
  }


  return false;
}
复制

定时持久化消息消费队列

// ConsumeQueue flush interval
private int flushIntervalConsumeQueue = 1000;
// How many pages are to be flushed when flush ConsumeQueue
private int flushConsumeQueueLeastPages = 2;
private int flushConsumeQueueThoroughInterval = 1000 * 60;


class FlushConsumeQueueService extends ServiceThread {
    private static final int RETRY_TIMES_OVER = 3;
    private long lastFlushTimestamp = 0;


    private void doFlush(int retryTimes) {
        int flushConsumeQueueLeastPages = DefaultMessageStore.this.getMessageStoreConfig().getFlushConsumeQueueLeastPages();


        if (retryTimes == RETRY_TIMES_OVER) {
            flushConsumeQueueLeastPages = 0;
        }


        long logicsMsgTimestamp = 0;


        int flushConsumeQueueThoroughInterval = DefaultMessageStore.this.getMessageStoreConfig().getFlushConsumeQueueThoroughInterval();
        long currentTimeMillis = System.currentTimeMillis();
        if (currentTimeMillis >= (this.lastFlushTimestamp + flushConsumeQueueThoroughInterval)) {
            this.lastFlushTimestamp = currentTimeMillis;
            flushConsumeQueueLeastPages = 0;
            logicsMsgTimestamp = DefaultMessageStore.this.getStoreCheckpoint().getLogicsMsgTimestamp();
        }


        ConcurrentMap<String, ConcurrentMap<Integer, ConsumeQueue>> tables = DefaultMessageStore.this.consumeQueueTable;


        for (ConcurrentMap<Integer, ConsumeQueue> maps : tables.values()) {
            for (ConsumeQueue cq : maps.values()) {
                boolean result = false;
                for (int i = 0; i < retryTimes && !result; i++) {
                    result = cq.flush(flushConsumeQueueLeastPages);
                }
            }
        }


        if (0 == flushConsumeQueueLeastPages) {
            if (logicsMsgTimestamp > 0) {
                DefaultMessageStore.this.getStoreCheckpoint().setLogicsMsgTimestamp(logicsMsgTimestamp);
            }
            DefaultMessageStore.this.getStoreCheckpoint().flush();
        }
    }


    public void run() {
        DefaultMessageStore.log.info(this.getServiceName() + " service started");


        while (!this.isStopped()) {
            try {
                int interval = DefaultMessageStore.this.getMessageStoreConfig().getFlushIntervalConsumeQueue();
                this.waitForRunning(interval);
                this.doFlush(1);
            } catch (Exception e) {
                DefaultMessageStore.log.warn(this.getServiceName() + " service has exception. ", e);
            }
        }


        this.doFlush(RETRY_TIMES_OVER);


        DefaultMessageStore.log.info(this.getServiceName() + " service end");
    }


    @Override
    public String getServiceName() {
        return FlushConsumeQueueService.class.getSimpleName();
    }


    @Override
    public long getJointime() {
        return 1000 * 60;
    }
}


public boolean flush(final int flushLeastPages) {
    boolean result = this.mappedFileQueue.flush(flushLeastPages);
    if (isExtReadEnable()) {
        result = result & this.consumeQueueExt.flush(flushLeastPages);
    }


    return result;
}
复制

数据库

文章转载自徘徊笔记，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。

RocketMQ源码分析之消息消费队列

评论

相关阅读
