Zipkin 持久化存入Elasticsearch

Java有货 2020-01-16

696

一.Zipkin服务端

1.1 依赖

 <properties>
        <java.version>1.8</java.version>
        <zipkin.version>2.9.4</zipkin.version>
        <zipkin.es.version>2.8.4</zipkin.es.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>io.zipkin.java</groupId>
            <artifactId>zipkin-server</artifactId>
            <version>${zipkin.version}</version>
            <exclusions>
                <exclusion>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-starter-log4j2</artifactId>
                </exclusion>
            </exclusions>
        </dependency>
        <dependency>
            <groupId>io.zipkin.java</groupId>
            <artifactId>zipkin-autoconfigure-ui</artifactId>
            <scope>runtime</scope>
            <version>${zipkin.version}</version>
        </dependency>
        <dependency>
            <groupId>io.zipkin.java</groupId>
            <artifactId>zipkin-autoconfigure-storage-elasticsearch-http</artifactId>
            <version>${zipkin.es.version}</version>
            <optional>true</optional>
        </dependency>
    </dependencies>

复制

1.2. 配置文件

zipkin.storage.StorageComponent=elasticsearch
zipkin.storage.type=elasticsearch
#可以做集群，我用的本地测试没有部署elastic集群
zipkin.storage.elasticsearch.hosts=192.168.42.40:9200
zipkin.storage.elasticsearch.cluster=elasticsearch
zipkin.storage.elasticsearch.index=zipkin
zipkin.storage.elasticsearch.index-shards=5
zipkin.storage.elasticsearch.index-replicas=1
maxHttpHeaderSize=8192
action.auto_create_index=true

复制

1.3. 启动类

@EnableZipkinServer//开启ZipkinServe
@SpringBootApplication(exclude = {DataSourceAutoConfiguration.class})
public class ZipkinApplication {

    public static void main(String[] args) {
        SpringApplication.run(ZipkinApplication.class, args);
    }
}

复制

二、客户端配置

2.1 SpringBoot 版本

2.1.1 依赖

<!-- zipkin-->
		<dependency>
			<groupId>io.zipkin.brave</groupId>
			<artifactId>brave-core</artifactId>
			<version>3.10.0</version>
		</dependency>
		<dependency>
			<groupId>io.zipkin.brave</groupId>
			<artifactId>brave-spancollector-http</artifactId>
			<version>3.10.0</version>
		</dependency>
		<dependency>
			<groupId>io.zipkin.brave</groupId>
			<artifactId>brave-web-servlet-filter</artifactId>
			<version>3.10.0</version>
		</dependency>
		<dependency>
			<groupId>io.zipkin.brave</groupId>
			<artifactId>brave-okhttp</artifactId>
			<version>3.10.0</version>
		</dependency>
		<!-- zipkin-->

复制

2.1.2 全局配置

@Data
@Configuration
@ConfigurationProperties(prefix = ZipkinConfig.ZIPKIN_PREFIX)
public class ZipkinConfig {

    public static final String ZIPKIN_PREFIX = "zipkin";

    //服务名称
    private String serviceName;

    //地址
    private String url;

    //连接时间
    private int connectTimeout;

    //读取时间
    private int readTimeout;

    //每间隔多少秒执行一次Span信息上传
    private int flushInterval;

    //是否启动压缩
    private boolean compressionEnabled;

    /**
     * @Description span（一次请求信息或者一次链路调用）信息收集器
     * @UserModule: exam-paper
     * @author Dylan
     * @date 2020/1/3
     * @param
     * @return com.github.kristofa.brave.SpanCollector
     */
    @Bean
    public SpanCollector spanCollector() {
        Config config = Config.builder()
                // 默认false，span在transport之前是否会被gzipped
                .compressionEnabled(compressionEnabled)
                .connectTimeout(connectTimeout)
                .flushInterval(flushInterval)
                .readTimeout(readTimeout)
                .build();
        return create(url, config, new EmptySpanCollectorMetricsHandler());
    }

    /**
     * @Description 作为各调用链路，只需要负责将指定格式的数据发送给zipkin
     * @UserModule: exam-paper
     * @author Dylan
     * @date 2020/1/3
     * @param spanCollector
     * @return com.github.kristofa.brave.Brave
     */
    @Bean
    public Brave brave(SpanCollector spanCollector) {
        //调用服务的名称
        Builder builder = new Builder(serviceName);
        builder.spanCollector(spanCollector);
        //采集率
        builder.traceSampler(Sampler.ALWAYS_SAMPLE);
        return builder.build();
    }

    /**
     * @Description 设置server的（服务端收到请求和服务端完成处理，并将结果发送给客户端）过滤器
     * @UserModule: exam-paper
     * @author Dylan
     * @date 2020/1/3
     * @param brave
     * @return com.github.kristofa.brave.servlet.BraveServletFilter
     */
    @Bean
    public BraveServletFilter braveServletFilter(Brave brave) {
        BraveServletFilter filter = new BraveServletFilter(brave.serverRequestInterceptor(),
                brave.serverResponseInterceptor(), new DefaultSpanNameProvider());
        return filter;
    }

    /**
     * @Description 设置client的（发起请求和获取到服务端返回信息）拦截器
     * @UserModule: exam-paper
     * @author Dylan
     * @date 2020/1/3
     * @param brave
     * @return okhttp3.OkHttpClient
     */
    @Bean
    public OkHttpClient okHttpClient(Brave brave) {
        OkHttpClient httpClient = new OkHttpClient.Builder()
                .addInterceptor(new BraveOkHttpRequestResponseInterceptor(
                        brave.clientRequestInterceptor(),
                        brave.clientResponseInterceptor(),
                        new DefaultSpanNameProvider())).build();
        return httpClient;
    }
}


复制

2.1.3 配置文件

zipkin.serviceName=exam-app
zipkin.url=http://localhost:8096
zipkin.connectTimeout=6000
zipkin.readTimeout=6000
zipkin.flushInterval=1
zipkin.compressionEnabled=true
management.endpoints.web.exposure.include="*"

复制

2.2 SpringCloud 版本

2.2.1 依赖

 <!--引入的zipkin依赖-->
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-zipkin</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-sleuth</artifactId>
        </dependency>

复制

2.2.2 配置文件

  zipkin:
    base-url: http://localhost:8096
    # 关闭服务发现，否则Spring Cloud会把zipkin的url当做服务名称
    discoveryClientEnabled: false
    sender:
      type: web
  sleuth:
    sampler:
      probability: 1  # 设置抽样采集率为100%，默认为0.1，即10%

复制
