一、AggregatingState的方法

AggregatingState需要和AggregateFunction配合使用

add()方法添加一个元素，触发AggregateFunction计算

get()获取State的值

二、AggregatingState描述器

在定义描述器时，第二个参数需要AggregateFunction类

//定义描述器
AggregatingStateDescriptor aggregatingStateDescriptor = new AggregatingStateDescriptor(
         "avg-temp",
         new SensorRecordUtils.MyAvgTemp(),
         TypeInformation.of(new TypeHint<Tuple2<Double, Integer>>(){})
 );

//获取ReducingState
aggregatingState = getRuntimeContext().getAggregatingState(aggregatingStateDescriptor);

复制

三、求key出现就进行求平均值

1、处理类

package test;

import org.apache.flink.api.common.functions.AggregateFunction;
import org.apache.flink.api.common.functions.RichFlatMapFunction;
import org.apache.flink.api.common.state.AggregatingState;
import org.apache.flink.api.common.state.AggregatingStateDescriptor;
import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.util.Collector;
/**
 * @program: Flink_GY
 * @description: AggregatingState求平均值
 * @author: Mr.逗
 * @create: 2021-09-09 11:35
 **/
public class CountAVgWithAggregatingState extends RichFlatMapFunction<Tuple2<Long, Long>, Tuple2<Long, Double>> {
    private AggregatingState<Tuple2<Long, Long>, Double> aggregatingState;
    //初始化
    @Override
    public void open(Configuration parameters) throws Exception {
        super.open(parameters);
//        AggregatingStateDescriptor<Tuple2<Long, Long>, Tuple2<Double, Integer>, Double> descriptor
        AggregatingStateDescriptor<Tuple2<Long,Long>,Tuple2<Long,Long>,Double> descriptor = new AggregatingStateDescriptor("AggregatingDescriptor", new AggregateFunction<Tuple2<Long, Long>, Tuple2<Long, Long>, Double>() {
            //初始化
            @Override
            public Tuple2<Long, Long> createAccumulator() {
                return Tuple2.of(0L, 0L);
            }

            @Override
            public Tuple2<Long, Long> add(Tuple2<Long, Long> value, Tuple2<Long, Long> accumulator) {
                Long currentCount = accumulator.f0;
                currentCount += 1;
                accumulator.f0 = currentCount;
                long sum=0;
                return new Tuple2<>(accumulator.f0, accumulator.f1+value.f1);
            }

            @Override
            public Double getResult(Tuple2<Long, Long> accumulator) {
                double avg=0;
                //当key出现三次进行求平均值
                if(accumulator.f0==3)
                {
                    avg= (double) accumulator.f1 / accumulator.f0;
                }
                return avg;
            }

            @Override
            public Tuple2<Long, Long> merge(Tuple2<Long, Long> a, Tuple2<Long, Long> b) {
                return new Tuple2<>(a.f0 + b.f0, a.f1 + b.f1);
            }
        }, Double.class);
        aggregatingState = getRuntimeContext().getAggregatingState(descriptor);
    }
    @Override
    public void flatMap(Tuple2<Long, Long> value, Collector<Tuple2<Long, Double>> out) throws Exception {
        aggregatingState.add(Tuple2.of(value.f0,value.f1));
        out.collect(Tuple2.of(value.f0,aggregatingState.get()));
    }
}

复制

2、主类

package test;

import org.apache.flink.api.java.tuple.Tuple2;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;

/**
 * @program: bigdata_learn
 * @description: 测试reduceState
 * @author: Mr.逗
 * @create: 2021-09-08 17:43
 **/
public class Test1KeyedReduceStateMain {
    public static void main(String[] args) throws  Exception{
        //获取执行环境
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        //StreamExecutionEnvironment.getExecutionEnvironment();
        //设置并行度
        env.setParallelism(16);
        //获取数据源
        DataStreamSource<Tuple2<Long, Long>> dataStreamSource =
                env.fromElements(
                        Tuple2.of(1L, 3L),
                        Tuple2.of(1L, 7L),
                        Tuple2.of(2L, 4L),
                        Tuple2.of(1L, 5L),
                        Tuple2.of(2L, 2L),
                        Tuple2.of(2L, 6L));


        // 输出：
        //(1,5.0)
        //(2,4.0)
        dataStreamSource
                .keyBy(0)
                .flatMap(new CountAVgWithAggregatingState())
                .print();
        String name = Test1KeyedReduceStateMain.class.getName();
        env.execute(name);
    }
}
复制

3、结果展示
