窗口的低语：解锁 Flink 窗口函数的秘密

DataStream<Tuple2<String, Long>> input = ...;


input
    .keyBy(<key selector>)
    .window(<window assigner>)
    .reduce(new ReduceFunction<Tuple2<String, Long>>() {
      public Tuple2<String, Long> reduce(Tuple2<String, Long> v1, Tuple2<String, Long> v2) {
        return new Tuple2<>(v1.f0, v1.f1 + v2.f1);
      }
    });

private static class AverageAggregate
    implements AggregateFunction<Tuple2<String, Long>, Tuple2<Long, Long>, Double> {
  @Override
  public Tuple2<Long, Long> createAccumulator() {
    return new Tuple2<>(0L, 0L);
  }


  @Override
  public Tuple2<Long, Long> add(Tuple2<String, Long> value, Tuple2<Long, Long> accumulator) {
    return new Tuple2<>(accumulator.f0 + value.f1, accumulator.f1 + 1L);
  }


  @Override
  public Double getResult(Tuple2<Long, Long> accumulator) {
    return ((double) accumulator.f0)  accumulator.f1;
  }


  @Override
  public Tuple2<Long, Long> merge(Tuple2<Long, Long> a, Tuple2<Long, Long> b) {
    return new Tuple2<>(a.f0 + b.f0, a.f1 + b.f1);
  }
}


DataStream<Tuple2<String, Long>> input = ...;


input
    .keyBy(<key selector>)
    .window(<window assigner>)
    .aggregate(new AverageAggregate());

DataStream<Tuple2<String, Long>> input = ...;


input
  .keyBy(t -> t.f0)
  .window(TumblingEventTimeWindows.of(Time.minutes(5)))
  .process(new MyProcessWindowFunction());


/* ... */


public class MyProcessWindowFunction
    extends ProcessWindowFunction<Tuple2<String, Long>, String, String, TimeWindow> {


  @Override
  public void process(String key, Context context, Iterable<Tuple2<String, Long>> input, Collector<String> out) {
    long count = 0;
    for (Tuple2<String, Long> in: input) {
      count++;
    }
    out.collect("Window: " + context.window() + "count: " + count);
  }
}

DataStream<SensorReading> input = ...;


input
  .keyBy(<key selector>)
  .window(<window assigner>)
  .reduce(new MyReduceFunction(), new MyProcessWindowFunction());


// Function definitions


private static class MyReduceFunction implements ReduceFunction<SensorReading> {


  public SensorReading reduce(SensorReading r1, SensorReading r2) {
      return r1.value() > r2.value() ? r2 : r1;
  }
}


private static class MyProcessWindowFunction
    extends ProcessWindowFunction<SensorReading, Tuple2<Long, SensorReading>, String, TimeWindow> {


  public void process(String key,
                    Context context,
                    Iterable<SensorReading> minReadings,
                    Collector<Tuple2<Long, SensorReading>> out) {
      SensorReading min = minReadings.iterator().next();
      out.collect(new Tuple2<Long, SensorReading>(context.window().getStart(), min));
  }
}

DataStream<Tuple2<String, Long>> input = ...;


input
  .keyBy(<key selector>)
  .window(<window assigner>)
  .aggregate(new AverageAggregate(), new MyProcessWindowFunction());


// Function definitions


/**
 * 累加器用于保存累加和和计数。
* The {@code getResult} method
 * computes the average.
 */
private static class AverageAggregate
    implements AggregateFunction<Tuple2<String, Long>, Tuple2<Long, Long>, Double> {
  @Override
  public Tuple2<Long, Long> createAccumulator() {
    return new Tuple2<>(0L, 0L);
  }


  @Override
  public Tuple2<Long, Long> add(Tuple2<String, Long> value, Tuple2<Long, Long> accumulator) {
    return new Tuple2<>(accumulator.f0 + value.f1, accumulator.f1 + 1L);
  }


  @Override
  public Double getResult(Tuple2<Long, Long> accumulator) {
    return ((double) accumulator.f0)  accumulator.f1;
  }


  @Override
  public Tuple2<Long, Long> merge(Tuple2<Long, Long> a, Tuple2<Long, Long> b) {
    return new Tuple2<>(a.f0 + b.f0, a.f1 + b.f1);
  }
}


private static class MyProcessWindowFunction
    extends ProcessWindowFunction<Double, Tuple2<String, Double>, String, TimeWindow> {


  public void process(String key,
                    Context context,
                    Iterable<Double> averages,
                    Collector<Tuple2<String, Double>> out) {
      Double average = averages.iterator().next();
      out.collect(new Tuple2<>(key, average));
  }
}

public class MyProcessFunction extends ProcessFunction<Event, Result> {


    @Override
    public void processElement(Event event, Context context, Collector<Result> collector) throws Exception {
        // 在这里编写处理逻辑
        // 可以根据业务需求进行各种操作，如数据转换、过滤、聚合等
        // 使用 collector 发送结果到下游


        // 示例：假设只处理 event.type 为 "click" 的事件
        if (event.getType().equals("click")) {
            // 将事件进行转换，生成 Result 对象，并发出到下游
            Result result = new Result(event.getUser(), event.getTimestamp());
            collector.collect(result);
        }
    }
}

public class MyCoProcessFunction extends CoProcessFunction<InputType1, InputType2, OutputType> {


    @Override
    public void processElement1(InputType1 value, Context ctx, Collector<OutputType> out) throws Exception {
        // 处理第一个输入流的元素
        // 使用 ctx 来访问时间戳、计时器等上下文信息
        // 使用 out.collect() 发送处理结果
    }


    @Override
    public void processElement2(InputType2 value, Context ctx, Collector<OutputType> out) throws Exception {
        // 处理第二个输入流的元素
        // 使用 ctx 来访问时间戳、计时器等上下文信息
        // 使用 out.collect() 发送处理结果
    }
}


StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();


DataStream<InputType1> inputStream1 = ...; // 创建第一个输入流
DataStream<InputType2> inputStream2 = ...; // 创建第二个输入流


DataStream<OutputType> outputStream = inputStream1
    .connect(inputStream2)
    .process(new MyCoProcessFunction());


outputStream.print();


env.execute("CoProcessFunction Example");

public class MergeStreamsFunction extends KeyedCoProcessFunction<KeyType, InputType1, InputType2, OutputType> {

  private ValueState<Integer> sumState;
  private ValueState<Integer> incrementState;

  @Override
  public void open(Configuration parameters) throws Exception {
    super.open(parameters);
    ValueStateDescriptor<Integer> sumStateDescriptor = new ValueStateDescriptor<>("sumState", Integer.class);
    sumState = getRuntimeContext().getState(sumStateDescriptor);

    ValueStateDescriptor<Integer> incrementStateDescriptor = new ValueStateDescriptor<>("incrementState", Integer.class);
    incrementState = getRuntimeContext().getState(incrementStateDescriptor);
  }

  @Override
  public void processElement1(InputType1 input1, Context context, Collector<OutputType> collector) throws Exception {
    // 处理第一个输入流的元素
    Integer increment = input1.getIncrement();
    incrementState.update(increment);

    Integer sum = sumState.value();
    if (sum == null) {
      sum = 0;
    }

    sum += increment;
    sumState.update(sum);

    collector.collect(new OutputType(input1.getKey(), sum, increment));
  }

  @Override
  public void processElement2(InputType2 input2, Context context, Collector<OutputType> collector) throws Exception {
    // 处理第二个输入流的元素
    Integer increment = incrementState.value();
    Integer sum = sumState.value();

    Integer newSum = sum + input2.getValue();

    collector.collect(new OutputType(input2.getKey(), newSum, increment));
  }
}

DataStream<Tuple2<String, String>> stream = ...;


// apply the process function onto a keyed stream
DataStream<Tuple2<String, Long>> result = stream
    .keyBy(value -> value.f0)
    .process(new CountWithTimeoutFunction());


/**
 * The data type stored in the state
 */
public class CountWithTimestamp {


    public String key;
    public long count;
    public long lastModified;
}


/**
 * The implementation of the ProcessFunction that maintains the count and timeouts
 */
public class CountWithTimeoutFunction
        extends KeyedProcessFunction<Tuple, Tuple2<String, String>, Tuple2<String, Long>> {


    /** The state that is maintained by this process function */
    private ValueState<CountWithTimestamp> state;


    @Override
    public void open(Configuration parameters) throws Exception {
        state = getRuntimeContext().getState(new ValueStateDescriptor<>("myState", CountWithTimestamp.class));
    }


    @Override
    public void processElement(
            Tuple2<String, String> value,
            Context ctx,
            Collector<Tuple2<String, Long>> out) throws Exception {


        // retrieve the current count
        CountWithTimestamp current = state.value();
        if (current == null) {
            current = new CountWithTimestamp();
            current.key = value.f0;
        }


        // update the state's count
        current.count++;


        // set the state's timestamp to the record's assigned event time timestamp
        current.lastModified = ctx.timestamp();


        // write the state back
        state.update(current);


        // schedule the next timer 60 seconds from the current event time
        ctx.timerService().registerEventTimeTimer(current.lastModified + 60000);
    }


    @Override
    public void onTimer(
            long timestamp,
            OnTimerContext ctx,
            Collector<Tuple2<String, Long>> out) throws Exception {


        // get the state for the key that scheduled the timer
        CountWithTimestamp result = state.value();


        // check if this is an outdated timer or the latest timer
        if (timestamp == result.lastModified + 60000) {
            // emit the state on timeout
            out.collect(new Tuple2<String, Long>(result.key, result.count));
        }
    }
}
