MySQL Update执行流程解读

GreatSQL社区 2022-04-01

437

* GreatSQL社区原创内容未经授权不得随意使用，转载请联系小编并注明来源。

一、update跟踪执行配置

使用内部程序堆栈跟踪工具path_viewer，跟踪mysql update 一行数据的执行过程, 配置执行脚本：call_update.sh

DROP DATABASE IF EXISTS d1;CREATE DATABASE d1;use d1;drop table if exists test;CREATE TABLE test (c0 int NOT NULL AUTO_INCREMENT,c1 date DEFAULT NULL,c2 time DEFAULT NULL,  c3 datetime DEFAULT NULL,  c4 year DEFAULT NULL,  c5 int DEFAULT NULL,  c6 decimal(10,6) DEFAULT NULL,  c7 double DEFAULT NULL,  c8 float DEFAULT NULL,  c9 varchar(255) DEFAULT NULL,  PRIMARY KEY (c0)) ENGINE=InnoDB AUTO_INCREMENT=5 DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci;INSERT INTO test VALUES ('1', '2021-04-26', '15:36:37', NULL, '2021', NULL, '6.000000', '7.1', '118.169', 'a8.168111');INSERT INTO test VALUES ('2', '2021-04-28', '15:36:37', '2021-04-27 15:36:41', '2021', '6', '7877.126000', '8.1', '119.187', 'a9.16');INSERT INTO test VALUES ('3', '2021-04-29', '15:36:37', '2021-04-27 15:36:41', '2021', '6', '7877.126890', '8.1', '119.187', 'a9.1682');INSERT INTO test VALUES ('4', '2021-04-30', '15:36:37', '2021-04-27 15:36:41', '2021', '6', '7877.126890', '8.1', '119.187', 'a9.168333');EOFsleep 1mysql -h127.0.0.1 -P3300 -uroot <<EOF use d1;\! ./util/start_trace.shupdate test set c7=10.1 where c0=1;\! ./util/end_trace.shEOF# analyse the data./util/seperate.sh $TOPIC 10000 5~

执行后，生成执行结果：

path_viewer/call_update$ ls362688_5.txt  362689.dat    362690.inf    362692_5.txt  362699.dat    362706.inf    362717_L.txt  mark.txt362688.dat    362689.inf    362691_5.txt  362692.dat    362699.inf    362717_5.txt  362717_M.txt  TDATA.trc362688.inf    362690_5.txt  362691.dat    362692.inf    362706_5.txt  362717.dat    362717_S.txt  THREADS.inf362689_5.txt  362690.dat    362691.inf    362699_5.txt  362706.dat    362717.inf    FUNC_DEF

查看SQL执行的函数调用过程362717_5.txt

 > my_net_set_read_timeout(NET*, unsigned int)        > vio_timeout(Vio*, unsigned int, int)            > vio_socket_timeout(Vio*, unsigned int, bool)            < vio_socket_timeout(Vio*, unsigned int, bool)        < vio_timeout(Vio*, unsigned int, int)    < my_net_set_read_timeout(NET*, unsigned int)    > dispatch_command(THD*, COM_DATA const*, enum_server_command)         > PROFILING::start_new_query(char const*)        < PROFILING::start_new_query(char const*)        > inline_mysql_refine_statement(PSI_statement_locker*, unsigned int)            > pfs_refine_statement_v2(PSI_statement_locker*, unsigned int)                > find_statement_class(unsigned int)                < find_statement_class(unsigned int)            < pfs_refine_statement_v2(PSI_statement_locker*, unsigned int)        < inline_mysql_refine_statement(PSI_statement_locker*, unsigned int)        > THD::set_command(enum_server_command)            > pfs_set_thread_command_vc(int)            < pfs_set_thread_command_vc(int)        < THD::set_command(enum_server_command)        > THD::clear_slow_extended()            > inline_mysql_mutex_unlock(mysql_mutex_t*, char const*, unsigned int)                > my_mutex_unlock(my_mutex_t*)                    > native_mutex_unlock(pthread_mutex_t*)                    < native_mutex_unlock(pthread_mutex_t*)                < my_mutex_unlock(my_mutex_t*)            < inline_mysql_mutex_unlock(mysql_mutex_t*, char const*, unsigned int)        < THD::clear_slow_extended()

.................................                   < MYSQLparse(THD*, Parse_tree_root**)                      > LEX::make_sql_cmd(Parse_tree_root*)                         > PT_update::make_cmd(THD*)                              > Parse_context::Parse_context(THD*, Query_block*)                            < Parse_context::Parse_context(THD*, Query_block*)                            > bool (anonymous namespace)::contextualize_safe<Parse_context, PT_with_clause*>(Parse_context*, PT_with_clause*)                            < bool (anonymous namespace)::contextualize_safe<Parse_context, PT_with_clause*>(Parse_context*, PT_with_clause*)                            > PT_table_factor_table_ident::contextualize(Parse_context*)                                > Query_block::add_table_to_list(THD*, Table_ident*, char const*, unsigned long, thr_lock_type, enum_mdl_type, List<Index_hint>*, List<String>*, MYSQL_LEX_STRING*, Parse_context*)                                    > check_table_name(char const*, unsigned long)                                    < check_table_name(char const*, unsigned long)                                    > memdup_root(MEM_ROOT*, void const*, unsigned long).................................             > Sql_cmd_dml::execute(THD*)                     > is_timer_applicable_to_statement(THD*)                    < is_timer_applicable_to_statement(THD*)                    > THD::push_internal_handler(Internal_error_handler*)                    < THD::push_internal_handler(Internal_error_handler*)                    > Sql_cmd_dml::prepare(THD*)                        > Sql_cmd_update::precheck(THD*)                            > check_one_table_access(THD*, unsigned long, TABLE_LIST*)                                > check_single_table_access(THD*, unsigned long, TABLE_LIST*, bool)                                    > check_access(THD*, unsigned long, char const*, unsigned long*, GRANT_INTERNAL_INFO*, bool, bool)                                        > get_cached_schema_access(GRANT_INTERNAL_INFO*, char const*)                                            > ACL_internal_schema_registry::lookup(char const*)                                            < ACL_internal_schema_registry::lookup(char const*)

.................................                            < THD::is_dml_gtid_compatible(bool, bool, bool)                        < THD::decide_logging_format(TABLE_LIST*)                    < lock_tables(THD*, TABLE_LIST*, unsigned int, unsigned int)                    > Sql_cmd_update::execute_inner(THD*)                         > Sql_cmd_update::update_single_table(THD*)                            > Query_expression::set_limit(THD*, Query_block*)                                > Query_block::get_offset(THD*)                                < Query_block::get_offset(THD*)                                > Query_block::get_limit(THD*)                                < Query_block::get_limit(THD*)                            < Query_expression::set_limit(THD*, Query_block*)                            > COPY_INFO::get_function_default_columns(TABLE*)                                > allocate_column_bitmap(TABLE*, MY_BITMAP**)                                    > multi_alloc_root(MEM_ROOT*, ...)                                    < multi_alloc_root(MEM_ROOT*, ...)                                < allocate_column_bitmap(TABLE*, MY_BITMAP**)                                > bitmap_is_clear_all(MY_BITMAP const*)                                < bitmap_is_clear_all(MY_BITMAP const*)

.................................                            > handler::ha_fast_update(THD*, mem_root_deque<Item*>&, mem_root_deque<Item*>&, Item*)                              < handler::ha_fast_update(THD*, mem_root_deque<Item*>&, mem_root_deque<Item*>&, Item*)                               > IndexRangeScanIterator::Read()                                 > QUICK_RANGE_SELECT::get_next()                                    > handler::ha_multi_range_read_next(char**)                                        > ha_innobase::multi_range_read_next(char**)

> DsMrr_impl::dsmrr_next(char**)                                                > handler::multi_range_read_next(char**)                                                    > quick_range_seq_next(void*, KEY_MULTI_RANGE*)                                                    < quick_range_seq_next(void*, KEY_MULTI_RANGE*)                                                    > ha_innobase::read_range_first(key_range const*, key_range const*, bool, bool)                                                        > handler::read_range_first(key_range const*, key_range const*, bool, bool)

.................................                            > handler::ha_update_row(unsigned char const*, unsigned char*)                                 > handler::mark_trx_read_write()                                < handler::mark_trx_read_write()                                > pfs_start_table_io_wait_v1(PSI_table_locker_state*, PSI_table*, PSI_table_io_operation, unsigned int, char const*, unsigned int)                                < pfs_start_table_io_wait_v1(PSI_table_locker_state*, PSI_table*, PSI_table_io_operation, unsigned int, char const*, unsigned int)                                > ha_innobase::update_row(unsigned char const*, unsigned char*)                                    > handler::ha_statistic_increment(unsigned long long System_status_var::*) const                                    < handler::ha_statistic_increment(unsigned long long System_status_var::*) const                                    > row_get_prebuilt_update_vector(row_prebuilt_t*)                                        > row_create_update_node_for_mysql(dict_table_t*, mem_block_info_t*)                                            > upd_node_create(mem_block_info_t*)                                                > mem_heap_zalloc(mem_block_info_t*, unsigned long)                                                    > mem_heap_alloc(mem_block_info_t*, unsigned long)                                                        > mem_block_get_len(mem_block_info_t*)                                                        < mem_block_get_len(mem_block_info_t*)                                                        > mem_block_get_free(mem_block_info_t*)                                                        < mem_block_get_free(mem_block_info_t*)                                                        > mem_block_get_free(mem_block_info_t*)                                                        < mem_block_get_free(mem_block_info_t*)                                                        > mem_block_set_free(mem_block_info_t*, unsigned long)                                                        < mem_block_set_free(mem_block_info_t*, unsigned long)                                                    < mem_heap_alloc(mem_block_info_t*, unsigned long)                                                < mem_heap_zalloc(mem_block_info_t*, unsigned long)                                                > mem_heap_create_func(unsigned long, unsigned long)

.................................                                                > __gnu_cxx::__exchange_and_add(int volatile*, int)                                                < __gnu_cxx::__exchange_and_add(int volatile*, int)                                            < __gnu_cxx::__exchange_and_add_dispatch(int*, int)                                        < QUICK_RANGE_SELECT::~QUICK_RANGE_SELECT()                                    < QUICK_RANGE_SELECT::~QUICK_RANGE_SELECT()                                < QEP_shared_owner::qs_cleanup()                            < QEP_TAB::cleanup()                        < Sql_cmd_update::update_single_table(THD*)                    < Sql_cmd_update::execute_inner(THD*)                    > THD::pop_internal_handler()                    < THD::pop_internal_handler()                    > Query_expression::cleanup(THD*, bool)                        > Query_block::cleanup(THD*, bool)                        < Query_block::cleanup(THD*, bool)                    < Query_expression::cleanup(THD*, bool)

二、执行分析

主要过程函数

do_command(THD*)      --从连接中读取命令dispatch_sql_command   --分发命令THD::sql_parser()      --SQL引擎层，词法语法分析  parse_sql       --SQL转换为AST语句    LEX::make_sql_cmd(Parse_tree_root*)  --解析树翻译成AST语法树     PT_update::make_cmd(THD*)   --生成命令对象，包含上下文处理     mysql_execute_command   --命令执行  Sql_cmd_dml::execute    Sql_cmd_dml::prepare(THD*)  --引用消解     Sql_cmd_update::precheck(THD*)  --更新语句实际执行的引用消解Sql_cmd_update::execute_inner(THD*)  --SQL引擎层，调用存储引擎接口执行  Sql_cmd_update::update_single_table(THD*)  optimize_cond  --执行优化器优化路径   handler::ha_fast_update ha_innobase::update_row   --innodb更新buffer pool 中table 的rowtrans_commit_stmt(THD*, bool)

innoDB关键更新执行过程

ha_innobase::update_row：row_get_prebuilt_update_vectorcalc_row_differencerow_update_for_mysql row_upd_step   row_upd   --执行更新    btr_pcur_t::restore_position    rec_get_offsets_func    btr_cur_update_in_place    btr_cur_upd_lock_and_undo    trx_undo_report_row_operation    trx_undo_create    trx_undo_seg_create     _fil_io     Fil_shard::do_io     pfs_os_aio_func    mtr_t::Command::execute     log_buffer_reserve     mtr_t::Command::add_dirty_blocks_to_flush_list ---脏数据快准备刷入磁盘    trx_undo_page_report_modifyrow_upd_rec_sys_fields row_upd_rec_in_placebtr_cur_update_in_place_log

更新过程描述:
