PostgreSQL-research/PostgreSQL PITR 基于时间线恢复探究

    #启用归档模式并配置归档命令    postgres=# ALTER SYSTEM SET archive_mode  = on;    ALTER SYSTEM    postgres=# ALTER SYSTEM SET archive_command  = 'cp %p /data2/archive/%f';    ALTER SYSTEM    postgres=# ALTER SYSTEM SET wal_level = 'replica';    ALTER SYSTEM    [postgres@server1 ~]$ pg_ctl  restart -D $PGDATA -l /tmp/logfile    waiting for server to shut down.... done    server stopped    waiting for server to start.... done    server started    #切换归档，以保证归档成功    postgres=# SELECT * FROM pg_switch_wal();     pg_switch_wal    ---------------     0/18D5580    (1 row)

    postgres=# \! ls /data2/archive    000000010000000000000001

    postgres=# \! ls $PGDATA/pg_wal    000000010000000000000001  000000010000000000000002  archive_status

    postgres=# CREATE TABLE tab_test(id integer,name varchar,gendate timestamp default current_timestamp);    CREATE TABLE    postgres=# INSERT INTO tab_test VALUES(1,'First');    INSERT 0 1    postgres=#  SELECT * FROM tab_test;     id | name  |          gendate    ----+-------+----------------------------      1 | First | 2022-05-09 15:52:56.258822    (1 row)

    [postgres@server1 ~]$ pg_basebackup -Ft -Xs -Pv -U postgres -c fast -D /data2/backup/    pg_basebackup: initiating base backup, waiting for checkpoint to complete    pg_basebackup: checkpoint completed    pg_basebackup: write-ahead log start point: 0/3000028 on timeline 1    pg_basebackup: starting background WAL receiver    pg_basebackup: created temporary replication slot "pg_basebackup_2314"    25426/25426 kB (100%), 1/1 tablespace    pg_basebackup: write-ahead log end point: 0/3000100    pg_basebackup: waiting for background process to finish streaming ...    pg_basebackup: syncing data to disk ...    pg_basebackup: renaming backup_manifest.tmp to backup_manifest    pg_basebackup: base backup completed

    postgres=# INSERT INTO tab_test VALUES(2,'After Backup');    INSERT 0 1    postgres=# SELECT * FROM tab_test;     id |     name     |          gendate    ----+--------------+----------------------------      1 | First        | 2022-05-09 15:52:56.258822      2 | After Backup | 2022-05-09 15:53:44.972818    (2 rows)

     postgres=# SELECT pg_switch_wal();     pg_switch_wal    ---------------     0/4000710    (1 row)

    postgres=# \! ls /data2/archive/ -lrth    total 65M    -rw------- 1 postgres postgres 16M May  9 15:51 000000010000000000000001    -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000002    -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000003    -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup    -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000004    postgres=# \! ls $PGDATA/pg_wal -lrth    total 49M    -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000003    -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup    -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000004    drwx------ 2 postgres postgres 133 May  9 15:54 archive_status    -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000005

 --查询一次时间，以方便恢复第二条数据,此刻只有两条数据        postgres=# SELECT * FROM current_timestamp;               current_timestamp        -------------------------------         2022-05-09 15:55:13.727361+08        (1 row)        postgres=# SELECT * FROM tab_test;         id |     name     |          gendate        ----+--------------+----------------------------          1 | First        | 2022-05-09 15:52:56.258822          2 | After Backup | 2022-05-09 15:53:44.972818        (2 rows) --然后再插入第三条数据        postgres=# INSERT INTO tab_test VALUES(3,'Third');        INSERT 0 1        postgres=# SELECT * FROM tab_test;         id |     name     |          gendate        ----+--------------+----------------------------          1 | First        | 2022-05-09 15:52:56.258822          2 | After Backup | 2022-05-09 15:53:44.972818          3 | Third        | 2022-05-09 15:56:06.301407        (3 rows)     --这里手动执行一次完整的检查点            postgres=# CHECKPOINT ;SELECT * FROM current_timestamp;            CHECKPOINT                   current_timestamp            -------------------------------             2022-05-09 15:56:23.438648+08            (1 row)

    postgres=# SELECT * FROM pg_switch_wal();         pg_switch_wal        ---------------         0/5000210        (1 row) --查询时间 （用来恢复包含第三条之前的数据）        postgres=# SELECT * FROM current_timestamp;               current_timestamp        -------------------------------         2022-05-09 15:56:48.871958+08        (1 row)

        postgres=# \! ls -lrth /data2/archive/        total 81M        -rw------- 1 postgres postgres 16M May  9 15:51 000000010000000000000001        -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000002        -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000003        -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup        -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000004        -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000005        postgres=#  \! ls -lrth $PGDATA/pg_wal        total 49M        -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup        -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000007        -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000005        drwx------ 2 postgres postgres  96 May  9 15:56 archive_status        -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000006

 --删除第二条数据        postgres=# DELETE FROM tab_test WHERE id = 2;        DELETE 1        postgres=# SELECT * FROM tab_test;         id | name  |          gendate        ----+-------+----------------------------          1 | First | 2022-05-09 15:52:56.258822          3 | Third | 2022-05-09 15:56:06.301407        (2 rows)

 --先查看归档        postgres=# \! ls -lrth /data2/archive/        total 81M        -rw------- 1 postgres postgres 16M May  9 15:51 000000010000000000000001        -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000002        -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000003        -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup        -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000004        -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000005        postgres=# \! ls -lrth $PGDATA/pg_wal        total 49M        -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup        -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000007        -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000005        drwx------ 2 postgres postgres  96 May  9 15:56 archive_status        -rw------- 1 postgres postgres 16M May  9 15:57 000000010000000000000006--正常停止        [postgres@server1 ~]$  pg_ctl  stop -D $PGDATA -l /tmp/logfile        waiting for server to shut down.... done        server stopped        [postgres@server1 ~]$--再次查看WAL 归档和 pg_wal     --正常停止自动做一次归档            [postgres@server1 ~]$ ls -lrth /data2/archive/            total 97M            -rw------- 1 postgres postgres 16M May  9 15:51 000000010000000000000001            -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000002            -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000003            -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup            -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000004            -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000005            -rw------- 1 postgres postgres 16M May  9 15:58 000000010000000000000006            [postgres@server1 ~]$ ls -lrth $PGDATA/pg_wal            total 49M            -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup            -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000008            -rw------- 1 postgres postgres 16M May  9 15:58 000000010000000000000006            -rw------- 1 postgres postgres 16M May  9 15:58 000000010000000000000007            drwx------ 2 postgres postgres  96 May  9 15:58 archive_status --删除数据目录        [postgres@server1 ~]$ cd $PGDATA        [postgres@server1 pgdata]$ rm -rf *

    [postgres@server1 ~]$ ps -ef | grep postgres | grep -Ev "grep|ps|bash|postgres"    #如果没有终止，杀掉进程

  [恢复到 9 小节记录第一次查询的时间点，此刻包含第二条数据

    [postgres@server1 pgdata]$ ls /data2/backup/    backup_manifest  base.tar  pg_wal.tar    [postgres@server1 pgdata]$ tar -xf /data2/backup/base.tar -C $PGDATA/

#这儿注意将之前的归档命令暂时注释掉，也可以不注释        [postgres@server1 pgdata]$ tail -2 $PGDATA/postgresql.auto.conf        restore_command = 'cp /data2/archive/%f %p'        recovery_target_time = '2022-05-09 15:55:13.727361+08'

    [postgres@server1 ~]$ touch $PGDATA/recovery.signal

--为了观察明显，先清空日志        [postgres@server1 pgdata]$ >/tmp/logfile        [postgres@server1 pgdata]$ pg_ctl start -D $PGDATA -l /tmp/logfile        waiting for server to start.... done        server started        [postgres@server1 pgdata]$ cat /tmp/logfile        2022-05-09 16:01:29.736 CST [2359] LOG:  starting PostgreSQL 14.2 on x86_64-pc-linux-gnu, compiled by gcc (GCC) 8.5.0 20210514 (Red Hat 8.5.0-10), 64-bit        2022-05-09 16:01:29.737 CST [2359] LOG:  listening on IPv6 address "::1", port 5532        2022-05-09 16:01:29.737 CST [2359] LOG:  listening on IPv4 address "127.0.0.1", port 5532        2022-05-09 16:01:29.737 CST [2359] LOG:  listening on Unix socket "/tmp/.s.PGSQL.5532"        2022-05-09 16:01:29.739 CST [2360] LOG:  database system was interrupted; last known up at 2022-05-09 15:53:14 CST        cp: cannot stat '/data2/archive/00000002.history': No such file or directory        2022-05-09 16:01:29.745 CST [2360] LOG:  starting point-in-time recovery to 2022-05-09 15:55:13.727361+08        2022-05-09 16:01:29.751 CST [2360] LOG:  restored log file "000000010000000000000003" from archive        2022-05-09 16:01:29.764 CST [2360] LOG:  redo starts at 0/3000028        2022-05-09 16:01:29.764 CST [2360] LOG:  consistent recovery state reached at 0/3000100        2022-05-09 16:01:29.764 CST [2359] LOG:  database system is ready to accept read-only connections        2022-05-09 16:01:29.771 CST [2360] LOG:  restored log file "000000010000000000000004" from archive        2022-05-09 16:01:29.796 CST [2360] LOG:  restored log file "000000010000000000000005" from archive        2022-05-09 16:01:29.809 CST [2360] LOG:  recovery stopping before commit of transaction 736, time 2022-05-09 15:56:06.301531+08        2022-05-09 16:01:29.809 CST [2360] LOG:  pausing at the end of recovery        2022-05-09 16:01:29.809 CST [2360] HINT:  Execute pg_wal_replay_resume() to promote.        [postgres@server1 pgdata]$

         postgres=# SELECT pg_wal_replay_resume();         pg_wal_replay_resume        ----------------------        (1 row)        postgres=# SELECT * FROM tab_test;         id |     name     |          gendate        ----+--------------+----------------------------          1 | First        | 2022-05-09 15:52:56.258822          2 | After Backup | 2022-05-09 15:53:44.972818        (2 rows)

    [postgres@server1 pgdata]$ pg_controldata   | grep -i timelineid    Latest checkpoint's TimeLineID:       2    Latest checkpoint's PrevTimeLineID:   1

    [postgres@server1 ~]$ ls -lrth /data2/archive/    total 97M    -rw------- 1 postgres postgres 16M May  9 15:51 000000010000000000000001    -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000002    -rw------- 1 postgres postgres 16M May  9 15:53 000000010000000000000003    -rw------- 1 postgres postgres 338 May  9 15:53 000000010000000000000003.00000028.backup    -rw------- 1 postgres postgres 16M May  9 15:54 000000010000000000000004    -rw------- 1 postgres postgres 16M May  9 15:56 000000010000000000000005    -rw------- 1 postgres postgres 16M May  9 15:58 000000010000000000000006    -rw------- 1 postgres postgres  50 May  9 16:01 00000002.history    [postgres@server1 ~]$ ls -lrth $PGDATA/pg_wal    total 65M    -rw------- 1 postgres postgres 16M May  9 16:01 000000020000000000000006    -rw------- 1 postgres postgres 16M May  9 16:01 000000020000000000000007    -rw------- 1 postgres postgres 16M May  9 16:01 000000010000000000000005    -rw------- 1 postgres postgres  50 May  9 16:01 00000002.history    drwx------ 2 postgres postgres  72 May  9 16:01 archive_status    -rw------- 1 postgres postgres 16M May  9 16:02 000000020000000000000005

--特别说明:        pg_wal 目录中有一个 00000002.history 的文件，该文件为 TimeLine 标识文件，并且在完成第一次恢复后，自动会将新增的该标识文件归档到归档目录(前提是归档依旧生效),并且 pg_wal 目录下会以新的 timeline 标识运行数据库        如下图表示        <--------timeline 1------------------>                     |             对应上面的三条数据             "First" "After Backup" "Third"        执行了一次恢复后，                     <-----timeline 2------------->                                                      包含 2 条数据                                                      "First" "After Backup"     --现在想要在 Timeline 2 的基础上，想要恢复 Timeline 1 中包含的三条数据的可行性探讨。            如果数据库中出现一个新的数据库化身，那么以前的数据对于当前的化身则不可用，因此如果在该化身上执行恢复            仅仅是当前新的化身周期内操作的数据可以被恢复，化身以外的操作不可用。因此想要恢复三条完整数据，只能在 Timeline 1 上进行操作恢复

 #插入数据        postgres=# INSERT INTO tab_test VALUES(4,'This item will be record in tli2');        INSERT 0 1        postgres=# SELECT * FROM pg_switch_wal();         pg_switch_wal        ---------------         0/5000528        (1 row)        postgres=# SELECT * FROM tab_test;         id |               name               |          gendate        ----+----------------------------------+----------------------------          1 | First                            | 2022-05-09 15:52:56.258822          2 | After Backup                     | 2022-05-09 15:53:44.972818          4 | This item will be record in tli2 | 2022-05-09 16:24:27.504229        (3 rows)    #假设此刻删除了 id = 1 的记录        postgres=# SELECT * FROM current_timestamp;               current_timestamp        -------------------------------         2022-05-09 16:25:34.959361+08        (1 row)        postgres=# DELETE FROM tab_test WHERE id = 1;        DELETE 1        postgres=# SELECT * FROM tab_test;         id |               name               |          gendate        ----+----------------------------------+----------------------------          2 | After Backup                     | 2022-05-09 15:53:44.972818          4 | This item will be record in tli2 | 2022-05-09 16:24:27.504229        (2 rows)    #停止数据库        [postgres@server1 ~]$ pg_ctl  stop -D $PGDATA -l /tmp/logfile        waiting for server to shut down.... done        server stopped    #执行恢复        #取回 timeline 1 的基础备份        #然后配置恢复文件        #创建信号文件        #启动数据库            --启动过程没有报错，但是日志报错,报错如下:            [postgres@server1 ~]$ >/tmp/logfile            [postgres@server1 ~]$ pg_ctl  start -D $PGDATA -l /tmp/logfile            waiting for server to start.... done            server started            [postgres@server1 ~]$ cat /tmp/logfile            2022-05-09 16:50:09.847 CST [2629] LOG:  starting PostgreSQL 14.2 on x86_64-pc-linux-gnu, compiled by gcc (GCC) 8.5.0 20210514 (Red Hat 8.5.0-10), 64-bit            2022-05-09 16:50:09.847 CST [2629] LOG:  listening on IPv6 address "::1", port 5532            2022-05-09 16:50:09.847 CST [2629] LOG:  listening on IPv4 address "127.0.0.1", port 5532            2022-05-09 16:50:09.848 CST [2629] LOG:  listening on Unix socket "/tmp/.s.PGSQL.5532"            2022-05-09 16:50:09.849 CST [2630] LOG:  database system was interrupted while in recovery at log time 2022-05-09 15:53:14 CST            2022-05-09 16:50:09.849 CST [2630] HINT:  If this has occurred more than once some data might be corrupted and you might need to choose an earlier recovery target.            2022-05-09 16:50:09.856 CST [2630] LOG:  restored log file "00000002.history" from archive            2022-05-09 16:50:09.856 CST [2630] LOG:  starting point-in-time recovery to 2022-05-09 16:47:02.768178+08            2022-05-09 16:50:09.858 CST [2630] LOG:  restored log file "00000002.history" from archive            2022-05-09 16:50:09.878 CST [2630] LOG:  restored log file "000000010000000000000003" from archive            2022-05-09 16:50:09.888 CST [2630] LOG:  redo starts at 0/3000028            2022-05-09 16:50:09.888 CST [2630] LOG:  consistent recovery state reached at 0/3000100            2022-05-09 16:50:09.888 CST [2629] LOG:  database system is ready to accept read-only connections            2022-05-09 16:50:09.895 CST [2630] LOG:  restored log file "000000010000000000000004" from archive            2022-05-09 16:50:09.917 CST [2630] LOG:  restored log file "000000020000000000000005" from archive            2022-05-09 16:50:09.936 CST [2630] LOG:  restored log file "000000020000000000000006" from archive            2022-05-09 16:50:09.958 CST [2630] LOG:  restored log file "000000020000000000000007" from archive            2022-05-09 16:50:09.980 CST [2630] LOG:  restored log file "000000020000000000000008" from archive            cp: cannot stat '/data2/archive/000000020000000000000009': No such file or directory            2022-05-09 16:50:09.997 CST [2630] LOG:  redo done at 0/80000F8 system usage: CPU: user: 0.00 s, system: 0.01 s, elapsed: 0.10 s            2022-05-09 16:50:09.997 CST [2630] LOG:  last completed transaction was at log time 2022-05-09 16:38:29.545234+08            2022-05-09 16:50:09.997 CST [2630] FATAL:  recovery ended before configured recovery target was reached            2022-05-09 16:50:09.997 CST [2629] LOG:  startup process (PID 2630) exited with exit code 1            2022-05-09 16:50:09.997 CST [2629] LOG:  terminating any other active server processes            2022-05-09 16:50:09.998 CST [2629] LOG:  shutting down due to startup process failure            2022-05-09 16:50:09.999 CST [2629] LOG:  database system is shut down

-----非常重要-----        在第一次恢复完成以后，一定要重新备份数据库集簇            [postgres@server1 ~]$ pg_basebackup -Ft -Xs -Pv -U postgres -c fast -D /data2/backup2/            pg_basebackup: initiating base backup, waiting for checkpoint to complete            pg_basebackup: checkpoint completed            pg_basebackup: write-ahead log start point: 0/6000028 on timeline 2            pg_basebackup: starting background WAL receiver            pg_basebackup: created temporary replication slot "pg_basebackup_2501"            25427/25427 kB (100%), 1/1 tablespace            pg_basebackup: write-ahead log end point: 0/6000100            pg_basebackup: waiting for background process to finish streaming ...            pg_basebackup: syncing data to disk ...            pg_basebackup: renaming backup_manifest.tmp to backup_manifest            pg_basebackup: base backup completed        --执行操作            postgres=# INSERT INTO tab_test VALUES(4,'This item will be record in tli2');            INSERT 0 1            postgres=# SELECT * FROM pg_switch_wal();             pg_switch_wal            ---------------             0/7000218            (1 row)            postgres=# SELECT * FROM tab_test;             id |               name               |          gendate            ----+----------------------------------+----------------------------              1 | First                            | 2022-05-09 15:52:56.258822              2 | After Backup                     | 2022-05-09 15:53:44.972818              4 | This item will be record in tli2 | 2022-05-09 16:37:47.275977            (3 rows)        --然后删除数据（也就是误操作）            postgres=# SELECT * FROM current_timestamp;                   current_timestamp            -------------------------------             2022-05-09 16:38:25.305327+08            (1 row)            postgres=# DELETE FROM tab_test WHERE id = 1;            DELETE 1            postgres=# SELECT * FROM tab_test;             id |               name               |          gendate            ----+----------------------------------+----------------------------              2 | After Backup                     | 2022-05-09 15:53:44.972818              4 | This item will be record in tli2 | 2022-05-09 16:37:47.275977            (2 rows)        --正常停止数据库            [postgres@server1 ~]$ pg_ctl  stop -D $PGDATA -l /tmp/logfile            waiting for server to shut down.... done            server stopped        --恢复过程            --取回基础备份（基于 timeline2的基础备份）                [postgres@server1 ~]$ rm -rf $PGDATA/*                [postgres@server1 ~]$ tar -xf /data2/backup2/base.tar -C $PGDATA/            --编辑配置文件                [postgres@server1 ~]$ tail -3 $PGDATA/postgresql.auto.conf                restore_command = 'cp /data2/archive/%f %p'                recovery_target_time = '2022-05-09 16:38:25.305327+08'                recovery_target_timeline = 2            --创建信号文件                [postgres@server1 ~]$ touch $PGDATA/recovery.signal            --启动数据库                [postgres@server1 ~]$ >/tmp/logfile                [postgres@server1 ~]$ pg_ctl  start -D $PGDATA -l /tmp/logfile                waiting for server to start.... done                server started                [postgres@server1 ~]$ cat /tmp/logfile                2022-05-09 16:44:30.394 CST [2528] LOG:  starting PostgreSQL 14.2 on x86_64-pc-linux-gnu, compiled by gcc (GCC) 8.5.0 20210514 (Red Hat 8.5.0-10), 64-bit                2022-05-09 16:44:30.394 CST [2528] LOG:  listening on IPv6 address "::1", port 5532                2022-05-09 16:44:30.394 CST [2528] LOG:  listening on IPv4 address "127.0.0.1", port 5532                2022-05-09 16:44:30.395 CST [2528] LOG:  listening on Unix socket "/tmp/.s.PGSQL.5532"                2022-05-09 16:44:30.396 CST [2529] LOG:  database system was interrupted; last known up at 2022-05-09 16:37:17 CST                2022-05-09 16:44:30.402 CST [2529] LOG:  restored log file "00000002.history" from archive                2022-05-09 16:44:30.402 CST [2529] LOG:  starting point-in-time recovery to 2022-05-09 16:38:25.305327+08                2022-05-09 16:44:30.404 CST [2529] LOG:  restored log file "00000002.history" from archive                2022-05-09 16:44:30.411 CST [2529] LOG:  restored log file "000000020000000000000006" from archive                2022-05-09 16:44:30.426 CST [2529] LOG:  redo starts at 0/6000028                2022-05-09 16:44:30.426 CST [2529] LOG:  consistent recovery state reached at 0/6000100                2022-05-09 16:44:30.426 CST [2528] LOG:  database system is ready to accept read-only connections                2022-05-09 16:44:30.433 CST [2529] LOG:  restored log file "000000020000000000000007" from archive                2022-05-09 16:44:30.451 CST [2529] LOG:  restored log file "000000020000000000000008" from archive                2022-05-09 16:44:30.462 CST [2529] LOG:  recovery stopping before commit of transaction 738, time 2022-05-09 16:38:29.545234+08                2022-05-09 16:44:30.462 CST [2529] LOG:  pausing at the end of recovery                2022-05-09 16:44:30.462 CST [2529] HINT:  Execute pg_wal_replay_resume() to promote.            --验证数据                [postgres@server1 ~]$ psql                psql (14.2)                Type "help" for help.                postgres=# SELECT pg_wal_replay_resume();                 pg_wal_replay_resume                ----------------------                (1 row)                postgres=# select * from tab_test;                 id |               name               |          gendate                ----+----------------------------------+----------------------------                  1 | First                            | 2022-05-09 15:52:56.258822                  2 | After Backup                     | 2022-05-09 15:53:44.972818                  4 | This item will be record in tli2 | 2022-05-09 16:37:47.275977                (3 rows)

    由于 id = 3 的数据位于 timeline 1 上，因此对于它的恢复，就是拿 timeline 1 的备份进行恢复    如下：    [root@server1 ~]# tar -xf /data2/backup/base.tar -C /data1/pgdata1/    [root@server1 ~]#    --编辑配置文件        [postgres@server1 ~]$ tail -4 /data1/pgdata1/postgresql.auto.conf        restore_command = 'cp /data2/archive/%f %p'        recovery_target_time = '2022-05-09 15:56:48.871958+08' #时间位置在 10 小节        recovery_target_timeline = 1 #指定时间线        port=5555    --创建信号文件        [postgres@server1 ~]$ touch /data1/pgdata1/recovery.signal    --启动数据库        [postgres@server1 ~]$ >/tmp/log5555        [postgres@server1 ~]$ pg_ctl start -D /data1/pgdata1/ -l /tmp/log5555        waiting for server to start.... done        server started        [postgres@server1 ~]$ cat /tmp/log5555        2022-05-09 17:06:13.795 CST [2812] LOG:  starting PostgreSQL 14.2 on x86_64-pc-linux-gnu, compiled by gcc (GCC) 8.5.0 20210514 (Red Hat 8.5.0-10), 64-bit        2022-05-09 17:06:13.795 CST [2812] LOG:  listening on IPv6 address "::1", port 5555        2022-05-09 17:06:13.795 CST [2812] LOG:  listening on IPv4 address "127.0.0.1", port 5555        2022-05-09 17:06:13.796 CST [2812] LOG:  listening on Unix socket "/tmp/.s.PGSQL.5555"        2022-05-09 17:06:13.797 CST [2813] LOG:  database system was interrupted while in recovery at log time 2022-05-09 15:53:14 CST        2022-05-09 17:06:13.797 CST [2813] HINT:  If this has occurred more than once some data might be corrupted and you might need to choose an earlier recovery target.        2022-05-09 17:06:13.801 CST [2813] LOG:  starting point-in-time recovery to 2022-05-09 15:56:48.871958+08        2022-05-09 17:06:13.807 CST [2813] LOG:  restored log file "000000010000000000000003" from archive        2022-05-09 17:06:13.826 CST [2813] LOG:  redo starts at 0/3000028        2022-05-09 17:06:13.826 CST [2813] LOG:  consistent recovery state reached at 0/3000100        2022-05-09 17:06:13.827 CST [2812] LOG:  database system is ready to accept read-only connections        2022-05-09 17:06:13.833 CST [2813] LOG:  restored log file "000000010000000000000004" from archive        2022-05-09 17:06:13.850 CST [2813] LOG:  restored log file "000000010000000000000005" from archive        2022-05-09 17:06:13.892 CST [2813] LOG:  restored log file "000000010000000000000006" from archive
        2022-05-09 17:06:13.906 CST [2813] LOG:  recovery stopping before commit of transaction 737, time 2022-05-09 15:57:38.329015+08
        2022-05-09 17:06:13.906 CST [2813] LOG:  pausing at the end of recovery
        2022-05-09 17:06:13.906 CST [2813] HINT:  Execute pg_wal_replay_resume() to promote.

    --验证数据
        [postgres@server1 ~]$ psql -p 5555
        psql (14.2)
        Type "help" for help.

        postgres=# select pg_wal_replay_resume() ;
         pg_wal_replay_resume
        ----------------------

        (1 row)

        postgres=# SELECT * FROM tab_test;
         id |     name     |          gendate
        ----+--------------+----------------------------
          1 | First        | 2022-05-09 15:52:56.258822
          2 | After Backup | 2022-05-09 15:53:44.972818
          3 | Third        | 2022-05-09 15:56:06.301407
        (3 rows)
