• 类关系图
• 封装的一些配置
• application.yml
• pom.xml
• 封装后使用
• MySQL 动态数据访问
• Mongo 动态数据访问
• ElasticSearch 动态数据访问(单个index+type)
• ElasticSearch 动态数据访问(多个index+type)
• 源代码托管

“

mysql, es, mongodb 三个数据源用配置文件方式连接，JPA只是正对dao做了封装，本文主要介绍如何对service层进行封装。

类关系图

• 对多个数据源连接获取数据进行统一封装
• ES spring-data方式不支持多个Index和Type的查找功能，添加了DynamicESDao支持
• 大大简化封装之后的调用, 调用方式如下

封装的一些配置

application.yml

banner:  charset: UTF-8  location: classpath:banner.txtserver:  port: 5555  contextPath: /  session:    timeout: 0spring:  application:    name: 'spring-boot-datasource-demo'  output:    ansi:      enabled: DETECT  messages:    basename: i18n/messages  thymeleaf:    cache: false  profiles:    active: dev  # MySQL data source settings  datasource:    url: jdbc:mysql://localhost:3306/cdc_standalone?useSSL=false    username: root    password: bfXa4Pt2lUUScy8jakXf  # MySQL JPA settings  jpa:    generate-ddl: true    show-sql: true    properties:      hibernate:        dialect: org.hibernate.dialect.MySQLDialect        format_sql: true  # NoSQL data source settings  data:    # MongoDB 2.2+ settings    mongodb:      uri: mongodb://standalone:fhY1tPt1lpUSbS7jwkTf@10.11.60.4:27017/standalone    # ElasticSearch settings    elasticsearch:      cluster-name: es-logs-01      cluster-nodes: 10.11.60.5:9300

pom.xml

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"    xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">    <modelVersion>4.0.0</modelVersion>    <groupId>spring-boot-datasource-demo</groupId>    <artifactId>spring-boot-datasource-demo</artifactId>    <version>0.0.1-SNAPSHOT</version>    <name>spring-boot-datasource-demo</name>    <description>spring-boot-datasource-demo</description>    <parent>        <groupId>org.springframework.boot</groupId>        <artifactId>spring-boot-starter-parent</artifactId>        <version>1.4.1.RELEASE</version>    </parent>    <properties>        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>        <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>        <java.version>1.8</java.version>        <commons.lang.version>3.3.2</commons.lang.version>        <springfox.version>2.7.0</springfox.version>    </properties>    <dependencies>        <dependency>            <groupId>org.springframework.boot</groupId>            <artifactId>spring-boot-starter</artifactId>        </dependency>        <dependency>            <groupId>org.springframework.boot</groupId>            <artifactId>spring-boot-starter-data-mongodb</artifactId>        </dependency>        <dependency>            <groupId>org.springframework.boot</groupId>            <artifactId>spring-boot-starter-data-elasticsearch</artifactId>        </dependency>        <dependency>            <groupId>org.springframework.boot</groupId>            <artifactId>spring-boot-starter-data-jpa</artifactId>        </dependency>        <dependency>            <groupId>mysql</groupId>            <artifactId>mysql-connector-java</artifactId>            <scope>runtime</scope>        </dependency>        <dependency>            <groupId>org.springframework.boot</groupId>            <artifactId>spring-boot-starter-web</artifactId>        </dependency>        <dependency>            <groupId>io.springfox</groupId>            <artifactId>springfox-swagger2</artifactId>            <version>${springfox.version}</version>        </dependency>        <dependency>            <groupId>io.springfox</groupId>            <artifactId>springfox-swagger-ui</artifactId>            <version>${springfox.version}</version>        </dependency>        <dependency>            <groupId>com.alibaba</groupId>            <artifactId>fastjson</artifactId>            <version>1.2.15</version>        </dependency>        <dependency>            <groupId>org.apache.commons</groupId>            <artifactId>commons-lang3</artifactId>            <version>${commons.lang.version}</version>        </dependency>        <dependency>            <groupId>org.apache.commons</groupId>            <artifactId>commons-collections4</artifactId>            <version>4.1</version>        </dependency>        <dependency>            <groupId>com.github.wenhao</groupId>            <artifactId>jpa-spec</artifactId>            <version>3.2.3</version>        </dependency>    </dependencies>    <build>        <sourceDirectory>src</sourceDirectory>        <plugins>            <plugin>                <artifactId>maven-compiler-plugin</artifactId>                <configuration>                    <source>1.8</source>                    <target>1.8</target>                </configuration>            </plugin>        </plugins>    </build></project>

封装后使用

“

封装之后使用将非常简单，公共的Service行为将被封装处理

MySQL 动态数据访问

“

通过几行代码即可实现对MySQL的访问，同时支持动态的条件查询；

• User

@Entity@Table(name = "tb_user")public class User extends BaseEntity {    private static final long serialVersionUID = 1L;    /**     * 用户id     */    @Id    @GeneratedValue(strategy = GenerationType.AUTO)    @Column(name = "id", nullable = false)    private Integer id;    private String userName;    private String nickName;    private String password;    private Integer sex;    private String telephone;    private String email;    private String address;    private Integer deleteStatus;    private Integer locked = 0;    private String description;    @JSONField(format = "yyyy-MM-dd HH:mm:ss")    private Date createTime;    @JSONField(format = "yyyy-MM-dd HH:mm:ss")    private Date updateTime;    @ManyToMany(cascade = { CascadeType.REFRESH }, fetch = FetchType.LAZY)    @JoinTable(name = "tb_user_role", joinColumns = { @JoinColumn(name = "user_id") }, inverseJoinColumns = {            @JoinColumn(name = "role_id") })    private java.util.Set<Role> roles;    // getter & setter}

• Dao

@Repositorypublicinterface IUserDao extends IBaseJpaDao<User, Integer>{}

• Service

public interface IUserService extends IBaseJpaService<User, Integer> {}@Servicepublic class UserServiceImpl extends BaseJpaServiceImpl<User, Integer> implements IUserService {    @Autowired    private IUserDao userDao;    @Override    public IBaseJpaDao<User, Integer> getBaseDao() {        return this.userDao;    }    @Override    public void delete(Integer id) {        User user = find(id);        Assert.state(!"admin".equals(user.getUserName()), "超级管理员用户不能删除");        super.delete(id);    }}

• Controller

@RestController@RequestMapping("/admin/user")public class UserController {    /**     * user service     */    @Autowired    private IUserService userService;    /**     * @param searchText     * @param user     * @param model     * @return     */    @GetMapping(value = "/list")    public List<User> list(@RequestParam(value = "searchText", required = false, defaultValue="a") String searchText) {        return userService.findAll(Specifications.<User>and().like("userName", "%" + searchText + "%").build());    }}

Mongo 动态数据访问

“

通过几行代码即可实现对Mongo的访问，同时支持动态的条件查询；

• Entity

@Document(collection = "security_alert_rules")public class EventRule extends BaseEntity {    private static final long serialVersionUID = -2013673868028645757L;    public static final int EVENT_STATUS_ENABLE = 0, EVENT_STATUS_DISABLE = 1;    private String component;    private String name;    private String eventId;    private String ciaLevel;    private String remarks;    private String script;    private long threshold;    private long timeWindow;    private String parseEsResultKeys;    private String nameCN;    private String remarkCN;    private String ruleType;    private String redisEventKey;    private int status = EVENT_STATUS_ENABLE;    // getter & setter}

• Dao

@Repositorypublic interface IEventRuleDao extends IBaseMongoDao<EventRule, String> {}

• Service

public interface IEventRuleService extends IBaseMongoService<EventRule, String> {}@Servicepublic class EventRuleServiceImpl extends BaseMongoServiceImpl<EventRule, String> implements IEventRuleService {    @Autowired    IEventRuleDao eventRuleDao;    @Override    public IBaseMongoDao<EventRule, String> getBaseDao() {        return eventRuleDao;    }}

• Controller

@RestController@RequestMapping("/admin/eventRule")public class EventRuleController {    /**     */    @Autowired    private IEventRuleService eventRuleService;    /**     * @param searchText     * @param user     * @param model     * @return     */    @GetMapping(value = "/list")    public List<EventRule> list(@RequestParam(value = "searchText", required = false) String searchText) {        EventRule param = new EventRule();        param.setName(searchText);//        Example<EventRule> rule = Example.<EventRule>of(param,//                ExampleMatcher.matching().withMatcher("name", ExampleMatcher.GenericPropertyMatchers.exact()));        Example<EventRule> rule = Example.<EventRule>of(param, ExampleMatcher.matching().withIgnoreCase("name","nameCN"));        return eventRuleService.findAll(rule);    }}

ElasticSearch 动态数据访问(单个index+type)

“

通过几行代码即可实现对ElasticSearch的访问，同时支持动态的条件查询；适合数据类型比较固定，且index和type独立的，比如强类型映射的实体类；

• Entity

@Document(indexName="syslog", type="logs")public class SysLog extends BaseEntity {    private static final long serialVersionUID = -4491916941883088972L;    @Id    private String _id;    private Set<String> phyPorts = new LinkedHashSet<>();    private Set<String> ports = new LinkedHashSet<>();    private String sensor;    private int vlan;    private Set<String> ip = new LinkedHashSet<>();    private Set<String> mac = new LinkedHashSet<>();    private String description;    private String type;    private String vendor;    private long timestamp;    private String name;    private String chassisId;    // getter & setter}

• Dao

@Repositorypublic interface ISysLogDao extends IBaseESDao<SysLog, String> {}

• Service

public interface ILogService extends IBaseESService<SysLog, String> {}@Servicepublic class LogServiceImpl extends BaseESServiceImpl<SysLog, String> implements ILogService {    @Autowired    ISysLogDao sysLogDao;    @Override    public IBaseESDao<SysLog, String> getBaseDao() {        return sysLogDao;    }}

• Controller

@RestController@RequestMapping("/admin/log")public class LogController {    /**     * user service     */    @Autowired    private ILogService logService;    /**     * @param searchText     * @param user     * @param model     * @return     */    @GetMapping(value = "/list")    public Page<SysLog> list(@RequestParam(value = "searchText", required = false) String searchText) {        return logService.search(QueryBuilders.matchQuery("_all", searchText), new PageRequest(0, 100));    }}

ElasticSearch 动态数据访问(多个index+type)

“

通过几行代码即可实现对ElasticSearch的访问，同时支持动态的条件查询；适合数据类型不固定，且index和type有多个，这些index具备相同结构类型，比如syslog-EVERY-DATE(由于日志量大，将每天的日志单独存放在一个Index中)；

• Entity

@Document(indexName="syslog", type="logs")public class SysLog extends BaseEntity {    private static final long serialVersionUID = -4491916941883088972L;    @Id    private String _id;    private Set<String> phyPorts = new LinkedHashSet<>();    private Set<String> ports = new LinkedHashSet<>();    private String sensor;    private int vlan;    private Set<String> ip = new LinkedHashSet<>();    private Set<String> mac = new LinkedHashSet<>();    private String description;    private String type;    private String vendor;    private long timestamp;    private String name;    private String chassisId;    // getter & setter}

• Dao

public interface IDymLogDao extends IDynamicEsDao<SysLog, String> {}@Repositorypublic class DymLogDaoImpl extends SimpleDynamicEsDaoImpl<SysLog, String> implements IDymLogDao {    @Autowired    protected ElasticsearchTemplate elasticsearchTemplate;    @Override    public ElasticsearchOperations getElasticsearchOperations() {        return elasticsearchTemplate;    }}

• Service

public interface IDymLogService extends IDynamicESService<SysLog, String> {}@Servicepublic class DymLogServiceImpl extends DynamicESServiceImpl<SysLog, String> implements IDymLogService {    @Autowired    IDymLogDao sysLogDao;    @Override    public IDynamicEsDao<SysLog, String> getBaseDao() {        return sysLogDao;    }}

• Controller

@RestController@RequestMapping("/admin/dymLog")public class DymLogController {    /**     * logService     */    @Autowired    private IDymLogService logService;    /**     * @param searchText     * @param user     * @param model     * @return     */    @GetMapping(value = "/list")
    public Page<SysLog> list(
            @RequestParam(value = "searchText", required = false, defaultValue = "Siemens") String searchText) {
        QueryBuilder queryBuilder = QueryBuilders.matchQuery("vendor", searchText);
        return logService.search(new NativeSearchQueryBuilder().withIndices("syslog-2018-12-17").withTypes("logs")
                .withQuery(queryBuilder).build());
    }
}

源代码托管

https://github.com/realpdai/springboot-data-multidatasource-demo
