SpringBoot中实现Redis的读写分离

起岸星辰 2021-06-21

2689

spring-boot-starter-data-redis
原生并不支持读写分离；因此需要我们去手动封装实现；实现思路：1.通过AOP来实现；2.封装工具类，我们在工具类里面实现；3.由使用者自己去处理。
这里我们通过再次封装redisTemplate类来实现，简化调用者的工作。

由于需要读写分离，因此我们需要自定义配置来实现。代码如下：

Redis自定义属性配置RedisReadWriteConfig

@Data
@Component
@ConfigurationProperties(prefix = "spring.redis")
public class RedisReadWriteConfig implements Serializable {


    /**
     * 主机地址
     */
    @Value("${spring.redis.host}")
    private String host;


    /**
     * 认证密码
     */
    @Value("${spring.redis.password:#{null}}")
    private String password;


    /**
     * 端口号
     */
    @Value("${spring.redis.port:6379}")
    private int port = 6379;


    /**
     * 数据库编号
     */
    @Value("${spring.redis.database:0}")
    private int database;


    /**
     * 连接超时时间，单位毫秒
     */
    @Value("${spring.redis.timeout:3000}")
    private long timeout;


    /**
     * 关闭超时时间，单位毫秒
     */
    @Value("${spring.redis.lettuce.shutdown-timeout:200}")
    private long shutdownTimeout;


    /**
     * 连接池中的最小空闲连接
     */
    @Value("${spring.redis.lettuce.pool.min-idle:1}")
    private int minIdle;


    /**
     * 连接池中的最大空闲连接
     */
    @Value("${spring.redis.lettuce.pool.max-idle:6}")
    private int maxIdle = 6;


    /**
     * 连接池最大连接数（使用负值表示没有限制,不要配置过大，否则可能会影响redis的性能）
     */
    @Value("${spring.redis.lettuce.pool.max-active:10}")
    private int maxActive = 10;


    /**
     * 连接池最大阻塞等待时间（使用负值表示没有限制），单位毫秒
     */
    @Value("${spring.redis.lettuce.pool.max-wait:1000}")
    private long maxWait = 1000;


    /**
     * redis只读库配置
     */
    private List<RedisReadConfig> redisReadConfigs;


    @Data
    @Validated
    @AllArgsConstructor
    @NoArgsConstructor
    static class RedisReadConfig {


        /**
         * 主机地址
         */
        @NotEmpty
        private String host;


        /**
         * 认证密码
         */
        private String password;


        /**
         * 端口号
         */
        private int port = 6379;


        /**
         * 数据库编号
         */
        private int database = 0;
    }


    /**
     * 只读实例配置
     *
     * @return 返回所有数据读取的配置
     */
    public List<RedisStandaloneConfiguration> buildReadRedisStandaloneConfiguration() {
        if (enableReadWriteModel()) {
            redisReadConfigs = redisReadConfigs.stream().distinct().collect(Collectors.toList());
            List<RedisStandaloneConfiguration> list = new ArrayList<>(redisReadConfigs.size());
            for(RedisReadConfig readConfig : redisReadConfigs){
                list.add(createRedisStandaloneConfiguration(readConfig));
            }
            return list;
        }
        return null;
    }


    /**
     * 写实例配置
     *
     * @return 返回所有数据读取的配置
     */
    public RedisStandaloneConfiguration buildWriteRedisStandaloneConfiguration() {
        RedisReadConfig redisServerConfig = new RedisReadConfig();
        redisServerConfig.setHost(this.host);
        redisServerConfig.setPort(this.port);
        redisServerConfig.setPassword(this.password);
        redisServerConfig.setDatabase(this.database);
        return createRedisStandaloneConfiguration(redisServerConfig);
    }


    /**
     * 是否启动读写分离模式
     *
     * @return 启用返回true；否则false
     */
    public boolean enableReadWriteModel(){
        return redisReadConfigs != null && !redisReadConfigs.isEmpty();
    }


    private RedisStandaloneConfiguration createRedisStandaloneConfiguration(RedisReadConfig redisServerConfig) {
        RedisStandaloneConfiguration redisStandaloneConfiguration = new RedisStandaloneConfiguration();
        // 连接地址
        redisStandaloneConfiguration.setHostName(redisServerConfig.getHost());
        // 认证密码
        redisStandaloneConfiguration.setPassword(redisServerConfig.getPassword());
        // 端口号，默认6379
        redisStandaloneConfiguration.setPort(redisServerConfig.getPort());
        // 数据库编号
        redisStandaloneConfiguration.setDatabase(redisServerConfig.getDatabase());
        return redisStandaloneConfiguration;
    }


}
复制

配置示例

server:
  port: 8088
spring:
  redis:
    # 地址
    host: 192.168.56.102
    # 端口号
    port: 6379
    # 密码
    password: 123456
    # 超时时间，单位毫秒
    timeout: 3000
    # 数据库编号
    database: 0
    # 配置lettuce
    lettuce:
      pool:
        # 连接池中的最小空闲连接
        min-idle: 1
        # 连接池中的最大空闲连接
        max-idle: 6
        # 连接池最大连接数（使用负值表示没有限制,不要配置过大，否则可能会影响redis的性能）
        max-active: 10
        # 连接池最大阻塞等待时间（使用负值表示没有限制）；单位毫秒
        max-wait: 1000
      #关闭超时时间；单位毫秒
      shutdown-timeout: 200
    # redis只读库配置
    redis-read-configs:
      - host: 192.168.56.104
        port: 6379
        password: 123456
      - host: 192.168.56.105
        port: 6379
        password: 123456
复制

自定义redis连接工厂ReadWriteLettuceConnectionFactory

由于我们有多个只读库，为了实现动态切换，我们自己是实现一个工厂，方便后面操作

@Slf4j
@Component
public class ReadWriteLettuceConnectionFactory implements DisposableBean {


    private final LettuceConnectionFactory writeConnectionFactory;


    private final List<LettuceConnectionFactory> readConnectionFactories = new ArrayList<>();


    private final AtomicInteger pos = new AtomicInteger();


    private int max = -1;


    public ReadWriteLettuceConnectionFactory(RedisReadWriteConfig readWriteConfig) {
        this.writeConnectionFactory = createLettuceConnectionFactory(readWriteConfig, readWriteConfig.buildWriteRedisStandaloneConfiguration());
        Assert.notNull(writeConnectionFactory, "redis config can not null, if don't used please remove dependence redis jar.");


        if (readWriteConfig.enableReadWriteModel()) {
            List<RedisStandaloneConfiguration> list = readWriteConfig.buildReadRedisStandaloneConfiguration();
            if(null!=list){
                for(RedisStandaloneConfiguration rsc:list){
                    LettuceConnectionFactory connectionFactory = createLettuceConnectionFactory(readWriteConfig, rsc);
                    if(connectionFactory!=null){
                        log.info("redis-read-datasource - load a datasource [{}:{}] success!", rsc.getHostName(), rsc.getPort());
                        readConnectionFactories.add(connectionFactory);
                        max++;
                    }else {
                        log.warn("redis-read-datasource - load a datasource [{}:{}] fail!", rsc.getHostName(), rsc.getPort());
                    }
                }
            }else {
                log.warn("found read redis config, but can't load a datasource fail!");
            }
        }
    }


    /**
     * 获取读连接池
     * @return  返回连接工厂
     */
    public LettuceConnectionFactory getReadFactory() {
        // 简单的负载均衡：轮询方案
        if(pos.get()>max){
            pos.set(0);
        }
        int index = pos.getAndIncrement();
        log.info("chose redis-read-datasource index is [{}]", pos);
        return getReadFactory(index);
    }


    private LettuceConnectionFactory getReadFactory(int index) {
        if(index>max){
            log.warn("no suitable redis-read-datasource [{}], the max {}.", index, max);
            // 发生错误自动切换到写连接上去
            return writeConnectionFactory;
        }
        return readConnectionFactories.get(index);
    }


    /**
     * 获取写连接池
     * @return  返回连接工厂
     */
    public LettuceConnectionFactory getWriteFactory() {
        return writeConnectionFactory;
    }


    /**
     * 创建Lettuce连接工厂
     *
     * @param readWriteConfig redis配置
     * @param redisStandaloneConfiguration redis独立配置
     * @return 返回连接工厂
     */
    private LettuceConnectionFactory createLettuceConnectionFactory(RedisReadWriteConfig readWriteConfig
            , RedisStandaloneConfiguration redisStandaloneConfiguration) {


        if (redisStandaloneConfiguration == null) {
            return null;
        }


        // 连接池配置
        GenericObjectPoolConfig poolConfig = new GenericObjectPoolConfig();
        // 连接池中的最小空闲连接
        poolConfig.setMinIdle(readWriteConfig.getMinIdle());
        // 连接池中的最大空闲连接
        poolConfig.setMaxIdle(readWriteConfig.getMaxIdle());
        // 连接池最大连接数（使用负值表示没有限制,不要配置过大，否则可能会影响redis的性能）
        poolConfig.setMaxTotal(readWriteConfig.getMaxActive());
        // 连接池最大阻塞等待时间（使用负值表示没有限制）
        poolConfig.setMaxWaitMillis(readWriteConfig.getMaxWait());


        LettucePoolingClientConfiguration.LettucePoolingClientConfigurationBuilder lettucePoolingClientConfigurationBuilder
                = LettucePoolingClientConfiguration.builder();
        // 连接池配置
        lettucePoolingClientConfigurationBuilder.poolConfig(poolConfig);
        // 关闭超时时间，单位毫秒
        lettucePoolingClientConfigurationBuilder.shutdownTimeout(Duration.ofMillis(readWriteConfig.getShutdownTimeout()));
        // 超时时间，单位毫秒
        lettucePoolingClientConfigurationBuilder.commandTimeout(Duration.ofMillis(readWriteConfig.getTimeout()));


        LettuceConnectionFactory lettuceConnectionFactory = new LettuceConnectionFactory(redisStandaloneConfiguration
                , lettucePoolingClientConfigurationBuilder.build());
        lettuceConnectionFactory.afterPropertiesSet();
        return lettuceConnectionFactory;
    }


    @Override
    public void destroy() throws Exception {
        writeConnectionFactory.destroy();
        if(!readConnectionFactories.isEmpty()){
            for(LettuceConnectionFactory connectionFactory:readConnectionFactories){
                connectionFactory.destroy();
            }
            readConnectionFactories.clear();
        }
        log.info("redis-datasource all closed success.");
    }
}
复制

重写RedisTemplate类实现多个只读库的动态切换

为了实现多个只读库能够自动的切换和轮询，需要对原来的RedisTemplate类做些升级，通过查看其源码发现每次执行相关操作前都会调用getRequiredConnectionFactory()
这个方法；基于此我们通过继承RedisTemplate
然后重写其getRequiredConnectionFactory()
方法来实现只读库的切换。

public class ReadWriteRedisTemplate<K, V> extends RedisTemplate<K, V> {


    private ReadWriteLettuceConnectionFactory readWriteConnectionFactory;


    private boolean isRead = false;


    /**
     * RedisTemplate每次执行方法时都会调用这个方法；如果只有1读1写，那么就没有必要再弄这个封装类，直接在创建的时候指定即可
     *
     * @return RedisConnectionFactory
     */
    @Override
    public RedisConnectionFactory getRequiredConnectionFactory() {
        return getFactory();
    }


    public void setReadWriteConnectionFactory(ReadWriteLettuceConnectionFactory readWriteConnectionFactory, boolean isRead) {
        this.isRead = isRead;
        this.readWriteConnectionFactory = readWriteConnectionFactory;
        setConnectionFactory(getFactory());
    }


    private RedisConnectionFactory getFactory(){
        if(this.isRead){
            return this.readWriteConnectionFactory.getReadFactory();
        }
        return this.readWriteConnectionFactory.getWriteFactory();
    }
}
复制

配置RedisTemplate的注入bean

@Configuration
public class RedisCachingConfigurer<K, V> extends CachingConfigurerSupport {


    /**
     * 读数据的RedisTemplate
     *
     * @param factory LettuceConnectionFactory
     */
    @Bean(name = "readRedisTemplate")
    public RedisTemplate<K, V> readRedisTemplate(ReadWriteLettuceConnectionFactory factory) {
        return redisTemplate(factory, true);
    }


    /**
     * 写数据的RedisTemplate
     *
     * @param factory LettuceConnectionFactory
     */
    @Bean(name = "writeRedisTemplate")
    public RedisTemplate<K, V> writeRedisTemplate(ReadWriteLettuceConnectionFactory factory) {
        return redisTemplate(factory, false);
    }


    private RedisTemplate<K, V> redisTemplate(ReadWriteLettuceConnectionFactory factory, boolean isRead) {
        //创建Redis缓存操作助手RedisTemplate对象
        ReadWriteRedisTemplate<K, V> template = new ReadWriteRedisTemplate<K, V>();
        template.setReadWriteConnectionFactory(factory, isRead);
        //设置key的序列化方式
        template.setKeySerializer(keySerializer());
        template.setHashKeySerializer(keySerializer());


        //将RedisTemplate的Value序列化方式由JdkSerializationRedisSerializer更换为Jackson2JsonRedisSerializer
        template.setValueSerializer(valueSerializer());
        template.setHashValueSerializer(valueSerializer());


        template.afterPropertiesSet();
        return template;
    }


    private RedisSerializer<String> keySerializer() {
        return new StringRedisSerializer();
    }


    private RedisSerializer<Object> valueSerializer() {
        Jackson2JsonRedisSerializer<Object> jackson2JsonRedisSerializer = new Jackson2JsonRedisSerializer<Object>(Object.class);


        ObjectMapper om = new ObjectMapper();
        // 指定要序列化的域，field,get和set,以及修饰符范围，ANY是都有包括private和public
        om.setVisibility(PropertyAccessor.ALL, JsonAutoDetect.Visibility.ANY);
        // 指定序列化输入的类型，类必须是非final修饰的，final修饰的类，比如String,Integer等会抛出异常
        om.activateDefaultTyping(LaissezFaireSubTypeValidator.instance, ObjectMapper.DefaultTyping.NON_FINAL);
        //解决时间序列化问题
        om.disable(SerializationFeature.WRITE_DATES_AS_TIMESTAMPS);
        om.registerModule(new JavaTimeModule());


        jackson2JsonRedisSerializer.setObjectMapper(om);
        return jackson2JsonRedisSerializer;
    }
}
复制

使用示例

@Autowired
private RedisTemplate<String, Student>  writeRedisTemplate;
@Autowired
private RedisTemplate<String, Student>  readRedisTemplate;


/**
 * 由使用者自己判断应该是读还是写；注意只读的只能做读操作
 */
@Override
public Student crud1() {
    // 获取数据
    Student val = this.readRedisTemplate.opsForValue().get("student-rw1:1");
    if (null == val) {
        log.info("缓存中数据不存在");
        val = Student.create();
        // 添加数据
        this.writeRedisTemplate.opsForValue().set("student-rw1:1", val);


        Student student2 = Student.create();
        student2.setId(2L);
        this.writeRedisTemplate.opsForValue().set("student-rw1:2", student2);
        this.writeRedisTemplate.opsForList().leftPush("student_list-rw1", val);
        this.writeRedisTemplate.opsForList().leftPush("student_list-rw1", student2);
    } else {
        // 删除数据
        this.writeRedisTemplate.delete("student-rw1:2");
        log.info("删除缓存");
    }
    log.info(JSON.toJSONString(val));


    // 获取列表数据
    List<Student> list = this.readRedisTemplate.opsForList().range("student_list-rw1", 0, 3);
    log.info(JSON.toJSONString(list));
    return val;
}
复制

封装工具类

从上面的例子上我们发现手动切换不是太方便，因此这里我封装一个帮助类

@Component
public class RedisHelper {


    private final RedisTemplate<String, String>  writeRedisTemplate;
    private final RedisTemplate<String, String>  readRedisTemplate;


    public RedisHelper(RedisTemplate<String, String> writeRedisTemplate, RedisTemplate<String, String> readRedisTemplate) {
        this.writeRedisTemplate = writeRedisTemplate;
        this.readRedisTemplate = readRedisTemplate;
    }


    /**
     * 设置值
     *
     * @param key 缓存key
     * @param value 值
     * @param <T> Class
     * @return 返回操作结果
     */
    public <T> boolean set(String key, T value) {
        if (value instanceof String) {
            return set(key, (String) value);
        }
        return set(key, JSON.toJSONString(value));
    }


    /**
     * 设置值
     *
     * @param key 缓存key
     * @param value 值
     * @param validTime 缓存时间，单位秒
     * @param <T> Class
     * @return 返回操作结果
     */
    public <T> boolean set(String key, T value, long validTime) {
        if (value instanceof String) {
            return set(key, (String) value, validTime);
        }
        return set(key, JSON.toJSONString(value), validTime);
    }


    /**
     * 设置值
     *
     * @param key 缓存key
     * @param value 值
     * @param validTime 缓存时间，单位秒
     * @return 返回操作结果
     */
    private boolean set(String key, String value, long validTime) {
        Boolean res = this.writeRedisTemplate.execute((RedisCallback<Boolean>) connection -> {
            RedisSerializer<String> serializer = this.writeRedisTemplate.getStringSerializer();
            byte[] keyByte = Objects.requireNonNull(serializer.serialize(key));
            byte[] valueByte = Objects.requireNonNull(serializer.serialize(value));
            connection.set(keyByte, valueByte);
            connection.expire(keyByte, validTime);
            return true;
        });
        return res != null && res;
    }


    /**
     * 设置某个值的缓存时间
     *
     * @param key 缓存key
     * @param validTime 缓存时间，单位秒
     * @return 返回操作结果
     */
    public boolean setExpire(String key, long validTime) {
        Boolean res = this.writeRedisTemplate.execute((RedisCallback<Boolean>) connection -> {
            RedisSerializer<String> serializer = this.writeRedisTemplate.getStringSerializer();
            byte[] keyByte = Objects.requireNonNull(serializer.serialize(key));
            connection.expire(keyByte, validTime);
            return true;
        });
        return res != null && res;
    }


    /**
     * 设置值
     *
     * @param key 缓存key
     * @param value 值
     * @return 返回操作结果
     */
    private boolean set(String key, String value) {
        Boolean res = this.writeRedisTemplate.execute((RedisCallback<Boolean>) connection -> {
            RedisSerializer<String> serializer = this.writeRedisTemplate.getStringSerializer();
            connection.set(Objects.requireNonNull(serializer.serialize(key)), Objects.requireNonNull(serializer.serialize(value)));
            return true;
        });
        return res != null && res;
    }


    /**
     * 获取值
     *
     * @param key 缓存key
     * @param clazz 反序列的Class
     * @param <T> T
     * @return 返回单个结果
     */
    public <T> T get(String key, Class<T> clazz) {
        return JSON.parseObject(getValue(key), clazz);
    }


    /**
     * 获取值
     *
     * @param key 缓存key
     * @param clazz 反序列的Class
     * @param <T> T
     * @return 返回List
     */
    public <T> List<T> getList(String key, Class<T> clazz) {
        return JSONArray.parseArray(getValue(key), clazz);
    }


    /**
     * 获取值
     *
     * @param key 缓存key
     * @return 返回单个结果
     */
    public String get(String key) {
        return getValue(key);
    }


    /**
     * 获取值
     *
     * @param key 缓存key
     * @return 返回单个结果
     */
    private String getValue(String key) {
        return this.readRedisTemplate.execute((RedisCallback<String>) connection -> {
            RedisSerializer<String> serializer = this.readRedisTemplate.getStringSerializer();
            byte[] value = connection.get(Objects.requireNonNull(serializer.serialize(key)));
            return serializer.deserialize(value);
        });
    }


    /**
     * 删除值
     *
     * @param key 缓存key
     */
    public void del(String key) {
        this.writeRedisTemplate.delete(key);
    }


    /**
     * 批量删除相同前缀的key
     *
     * @param prefix 前缀
     */
    public void batchDel(String prefix) {
        Set<String> keys = keys(prefix);
        if (null != keys && !keys.isEmpty()) {
            this.writeRedisTemplate.delete(keys);
        }
    }


    /**
     * 批量删除
     *
     * @param keys 需要删除的key
     */
    public void batchDel(Collection<String> keys) {
        this.writeRedisTemplate.delete(keys);
    }


    /**
     * 判断值缓存key是否存在
     *
     * @param key 缓存key
     */
    public boolean exist(String key) {
        Boolean res = this.writeRedisTemplate.hasKey(key);
        return res != null && res;
    }


    /**
     * 获取相同前缀的key
     *
     * @param prefix 前缀
     */
    public Set<String> keys(String prefix) {
        return this.readRedisTemplate.keys(prefix + "*");
    }


    /**
     * 如果key不存在则设置，此方法使用了redis的原子性
     *
     * @param key       key
     * @param value     value
     * @param validTime 缓存时间; 若要是使用锁，建议设置有效时间，避免死锁
     * @return key不存在设置成功返回true; 否则返回false
     */
    public boolean setNx(String key, String value, long validTime) {
        return setNx(key, value, validTime, TimeUnit.SECONDS);
    }


    /**
     * 如果key不存在则设置，此方法使用了redis的原子性
     *
     * @param key       key
     * @param value     value
     * @param validTime 缓存时间; 若要是使用锁，建议设置有效时间，避免死锁
     * @param timeUnit  时间单位
     * @return key不存在设置成功返回true; 否则返回false
     */
    public boolean setNx(String key, String value, long validTime, TimeUnit timeUnit) {
        try {
            ValueOperations<String, String> operations = this.writeRedisTemplate.opsForValue();
            Boolean lock = operations.setIfAbsent(key, value, validTime, timeUnit);
            return lock != null && lock;
        } catch (Exception e) {
            this.del(key);
            e.printStackTrace();
        }
        return false;
    }
}
复制

使用示例

@Autowired
private RedisHelper redisHelper;
/**
 * 通过工具类自动切换
 */
@Override
public Student crud2() {
    // 获取数据
    Student val = this.redisHelper.get("student-rw2:1", Student.class);
    if (null == val) {
        log.info("缓存中数据不存在");
        val = Student.create();
        // 添加数据
        this.redisHelper.set("student-rw2:1", val);


        Student student2 = Student.create();
        student2.setId(2L);
        this.redisHelper.set("student-rw2:2", student2);


        List<Student> list = Lists.newArrayList(val, student2);
        this.redisHelper.set("student_list-rw2", list);


    } else {
        // 删除数据
        this.redisHelper.del("student-rw2:2");
        log.info("删除缓存");
    }
    log.info(JSON.toJSONString(val));
    // 获取列表数据
    List<Student> list = this.redisHelper.getList("student_list-rw2", Student.class);
    log.info(JSON.toJSONString(list));
    return val;
}
复制

redis

文章转载自起岸星辰，如果涉嫌侵权，请发送邮件至：contact@modb.pro进行举报，并提供相关证据，一经查实，墨天轮将立刻删除相关内容。
