PostgreSQL 高可用集群

安装指南

2018.5

I

目  录

一、  主机拓扑结构信息 ............................................................................................................................1
1.  版本信息 ..........................................................................................................................................1
2.  主机信息 ..........................................................................................................................................1
3.  拓扑结构 ..........................................................................................................................................1
二、  安装配置集群 .....................................................................................................................................1
1.  安装初始化 PG ...............................................................................................................................1
1)  安装步骤 ..........................................................................................................................................1
2)  建立归档目录 ................................................................................................................................2
2.  数据库配置 .....................................................................................................................................2
1)  创建复制用户 ................................................................................................................................2
2)  修改数据库配置 ............................................................................................................................3
a.  postgresql.conf .........................................................................................................................3
b.  pg_hba.conf ...................................................................................................................................5
3)  restart database .......................................................................................................................5
3.  sync slave 配置 ...........................................................................................................................5
1)  停止数据库 .....................................................................................................................................5
2)  清空 pgdata 目录 .........................................................................................................................5
3)  配置 sync standby .....................................................................................................................5
4)  配置恢复同步与切换...................................................................................................................6
5)  启动 sync slave ...........................................................................................................................6
4.  async slave 配置 .......................................................................................................................7
1)  停止数据库 .....................................................................................................................................7
2)  清空 pgdata 目录 .........................................................................................................................7
3)  配置 async slave ........................................................................................................................7
4)  配置 wal 时间线切换 .................................................................................................................8
5)  启动 async standby...................................................................................................................8
5.  检查 replication 状态 ..............................................................................................................8
1)  primary ............................................................................................................................................8
2)  sync standby ............................................................................................................................. 10
3)  async standby ........................................................................................................................... 12


一、主机拓扑结构信息

1. 版本信息

OS：CentOS Linux release 7.4.1708 X64

PostgreSQL: postgresql10-server-10.3-1PGDG.rhel7.x86_64

2. 主机信息

cluster01_node01 192.168.0.108

cluster01_node02 192.168.0.109

cluster02_node03 192.168.0.110

3. 拓扑结构

初始状态：

sync async

primary(cls01_node01)--->standby01(cls01_node02) --->standby02(cls01_node03)

二、安装配置集群

1. 安装初始化 PG

三个节点 cls01_node01，cls01_node02，cls01_node03。

1) 安装步骤

--- install pg packages

yum install https://download.postgresql.org/pub/repos/yum/10/redhat/rhel-7-

x86_64/pgdg-centos10-10-2.noarch.rpm

yum install postgresql10-server

yum install -y postgresql10-contrib

--- init and auto boot

primary

async standby

sync standby

async

sync
