Oracle
®
Enterprise Manager
System Monitoring Plug-in Installation Guide for Oracle Big Data Appliance
13c Release 2
E74773-01
June 2016
This document describes how to set up Oracle Big Data Appliance for monitoring
within Enterprise Manager Cloud Control. The document contains the following
sections:
• Description
• Versions Supported
• Prerequisites
• Deploying the Big Data Appliance Plug-in on OMS
• Performing Rediscovery to Synchronize Cluster Configuration Changes
• Performing Post-Discovery Configuration and Verification
• Verifying and Validating the Plug-in
• Performing Administrative Tasks
• Undeploying the Big Data Appliance Plug-in
• Documentation Accessibility
Description
Oracle Big Data Appliance is an engineered system of hardware and software
optimized to capture and analyze the massive volumes of unstructured data generated
by social media feeds, email, web logs, photographs, smart meters, sensors, and
similar devices.
Oracle Big Data Appliance is engineered to work with Oracle Exadata Database
Machine and Oracle Exalytics In-Memory Machine to provide the most advanced
analysis of all data types, with enterprise-class performance, availability,
supportability, and security.
The Oracle Linux operating system and Cloudera's Distribution including Apache
Hadoop (CDH) underlie all other software components installed on Oracle Big Data
Appliance.
The Oracle Enterprise Manager Big Data Appliance plug-in enables you to use the
same system monitoring tool for Oracle Big Data Appliance as you use for Oracle
Exadata Database Machine or any other Oracle Database installation. With the plug-in,
1
you can view the status of the installed software components in tabular or graphic
presentations, and start and stop these software services. You can also monitor the
health of the network and the rack components.
In Enterprise Manager you can monitor all Oracle Big Data Appliance racks on the
same InfiniBand fabric. You can see summary views of both the rack hardware and the
software layout of the logical clusters.
You can also do the following:
• Discover the components of a Big Data Appliance Network and add them as
managed targets.
• Manage the hardware and software components that comprise a Big Data
Appliance Network as a single target or as individual targets.
• Study collected metrics to analyze the performance of the network and each BDA
component.
• Trigger alerts based on availability and system health.
• Respond to warnings and incidents.
Versions Supported
The Oracle Enterprise Manager Big Data Appliance plug-in requires the following
versions of products:
• Enterprise Manager Cloud Control 13c Release x (and earlier 12.1.0.x supported
versions)
• CDH, Cloudera's Distribution including Apache Hadoop 5.x (and earlier
supported versions)
• Oracle Big Data Appliance 3.0 or later
Prerequisites
The following prerequisites must be met before you can deploy the Big Data
Appliance plug-in:
• •A supported version of Enterprise Manager Cloud Control is installed and up and
running. Enterprise Manager can be installed anywhere in the network, provided
the Big Data Appliance machines are visible from the location. For performance
reasons, try to install Enterprise Manager such that there is minimal latency when
connecting to Big Data Appliance machines.
• Oracle representative has set up Oracle Big Data Appliance hardware.
• Oracle representative has run the Mammoth utility to install Oracle Big Data
Appliance software on the 18 servers in the rack. The utility also installs
Management Agents on all the servers and performs automatic discovery of Big
Data Appliance Network targets.
2
Before running the utility, ensure that the Oracle Management Service (OMS) has
the necessary platform agent image as described in Synchronizing the Agent Image
on OMS. See also About the Mammoth Utility.
• •The Oracle Big Data Appliance plug-in has an engineered systems dependency
for hardware monitoring. For Enterprise Manager 12.1.0.x, the appropriate Oracle
Exadata plug-in should already be deployed on OMS. For Enterprise Manager 13c
Release x, the appropriate Systems Infrastructure plug-in should already be
deployed on OMS. In either case, these are default plug-ins and should always be
available.
Synchronizing the Agent Image on OMS
If the OS where the Management Agent is to be installed differs from the OS where
Oracle Management Service is installed, you must install the agent image that matches
the Management Agent OS. By default, OMS has the same agent image as the platform
on which it is installed. So, for example, if OMS is installed on a solaris64 platform, it
has the agent image for solaris64. If the Management Agent is to be installed on a
linux64 platform and OMS is on a solaris64 platform, you must install the agent image
for linux64 on the OMS host.
Use the Self Update feature to download and apply the required agent image. To use
Self Update effectively, note the following requirements:
• The Software Library must be configured.
• MOS credentials must be set.
• There can be no refresh errors on the Self Update page (typically indicates a
problem with the MOS credentials; try resetting the credentials).
• Allow time for the refresh job to complete (select Check Updates on the Self
Update page Actions menu to speed the process).
To use the Self Update feature:
1. From the Setup menu, select Extensibility, then select Self Update.
Ensure that the connection mode is success and that the most recent refresh
occurred within the past 24 hours.
2. Click Agent Software and select the image for the platform you need.
3. Download and apply the selected agent image.
Proceed with BDA installation.
About the Mammoth Utility
Mammoth is a command-line utility for installing and configuring the Oracle Big Data
Appliance software. Using Mammoth, you can:
• Set up a cluster for either CDH or Oracle NoSQL Database.
• Create a cluster on one or more racks.
• Create multiple clusters on an Oracle Big Data Appliance rack.
3
