目 录
1、建立存放备份目录 2、原库全量备份 3、新库重建密码文件 4、新建参数文件，按照源库修改 5、新建目录 6、修改 .bash_profile 7、修改 /etc/hosts 文件添加主机名 8、恢复控制文件 9、启动数据库至 mount 状态 10、生成修改路径的语句 11、目标库恢复 rman 进行恢复 恢复归档 12、恢复后的清理操作 删除未使用的 redo 清除多余的 undo 添加 redo 日志组 13、验证数据库 14、配置监听和 TNS 15、设置删除归档策略复制
前 言
备份和恢复都是数据库管理中非常重要的任务，用于保护数据库免受故障和灾难的影响。在 Oracle 数据库中，备份和恢复可以通过多种方式实现。一种常见的备份方式是使用 Oracle RMAN（Recovery Manager）工具进行备份。RMAN 可以创建全备份、增量备份和归档日志备份等多种备份类型，可以将备份数据存储在磁盘、磁带等多种介质上。在恢复数据时，可以使用 RMAN 工具执行恢复操作。
如果数据库无法启动，可以使用恢复目录和备份集创建一个临时的控制文件，以便进行数据库恢复。RMAN 还支持基于时间点的恢复，可以将数据库恢复到指定的时间点或SCN（System Change Number）。
下面是以前做备份恢复的一种通用方式，特此记录下来，以备后续参考需要。
1、建立存放备份目录
su - oracle mkdir -p /backup/backup/backup20200521 sqlplus / as sysdba复制
2、原库全量备份
原库切换日志进行备份
alter system archive log current;复制
原库利用 rman 备份片生成备份（由于不知道主库 sys 密码，数据量也较小，使用RMAN 备份传输至备库）
rman target / run { allocate channel c1 type disk ; allocate channel c2 type disk ; allocate channel c3 type disk ; allocate channel c4 type disk ; backup as compressed backupset database format '/backup/backup/backup20200521/%d_%I_%s_%p.bak'; backup as compressed backupset archivelog all format '/backup/backup/backup20200521/%d_%I_%s_%p.arc'; backup current controlfile format '/backup/backup/backup20200521/%d_%I_%s_%p.ctl'; release channel c1; release channel c2; release channel c3; release channel c4; }复制
3、新库重建密码文件
su - oracle cd $ORACLE_HOME/dbs orapwd file=orapwjiekexu1 password=oracle11g复制
或者拷贝原库 cp $ORACLE_HOME/dbs/orapw* 到目标库 dbs 目录下。
4、新建参数文件，按照源库修改
jiekexu1.__db_cache_size=6174015488 jiekexu1.__java_pool_size=16777216 jiekexu1.__large_pool_size=33554432 jiekexu1.__oracle_base='/app/oracle'#ORACLE_BASE set from environment jiekexu1.__pga_aggregate_target=2483027968 jiekexu1.__sga_target=7449083904 jiekexu1.__shared_io_pool_size=0 jiekexu1.__shared_pool_size=1174405120 jiekexu1.__streams_pool_size=0 *.audit_file_dest='/app/oracle/admin/jiekexu/adump' *.audit_trail='NONE' *.compatible='11.2.0.4.0' *.control_file_record_keep_time=39 *.control_files='/oradata/jiekexu/controlfile/control01.ctl' *.db_block_size=8192 *.db_create_file_dest='/oradata' *.db_domain='' *.db_files=1024 *.db_name='JIEKEXU' *.diagnostic_dest='/app/oracle' *.dispatchers='(PROTOCOL=TCP) (SERVICE=jiekexuXDB)' *.enable_ddl_logging=TRUE jiekexu1.instance_number=1 *.log_archive_dest_1='LOCATION=/oradata/arch' *.log_archive_format='%t_%s_%r.dbf' *.open_cursors=500 *.pga_aggregate_target=2474639360 *.processes=2000 *.query_rewrite_enabled='TRUE' *.query_rewrite_integrity='TRUSTED' *.remote_login_passwordfile='exclusive' *.session_cached_cursors=100 *.sessions=2205 *.sga_max_size=7449083904 *.sga_target=7449083904 jiekexu1.thread=1 *.undo_retention=1440 jiekexu1.undo_tablespace='UNDOTBS1' *.local_listener=''复制
5、新建目录
以上参数文件中出现的目录均需要创建
mkdir -p /app/oracle/admin/jiekexu/adump mkdir -p /oradata/jiekexu/controlfile mkdir -p /oradata/arch复制
6、修改 .bash_profile
拷贝原环境 .bash_profile 进行修改。
umask 022 ORACLE_BASE=/u01/app/oracle ORACLE_HOME=/u01/app/oracle/product/11.2.0/dbhome_1/ ORACLE_SID=jiekexu1 #NLS_LANG="SIMPLIFIED CHINESE_CHINA".UTF8 PATH=$PATH:$HOME/.local/bin:$HOME/bin:$ORACLE_HOME/bin #LANG=zh_CN.UTF-8 export LANG=en_US.UTF8 export NLS_LANG="AMERICAN_AMERICA.AL32UTF8" export NLS_DATE_FORMAT="YYYY-MM-DD HH24:MI:SS" export PATH LANG NLS_LANG ORACLE_BASE ORACLE_HOME ORACLE_SID #使环境生效 alias sqlplus='/usr/local/bin/rlwrap sqlplus' alias rman='/usr/local/bin/rlwrap rman' alias sys='sqlplus / as sysdba' export LD_LIBRARY_PATH=$ORACLE_HOME/lib:$ORACLE_HOME/lib32:$OGG_HOME:/lib/usr/lib:/usr/local/lib --source 生效 source .bash_profile复制
7、修改 /etc/hosts 文件添加主机名
127.0.0.1 localhost 127.0.0.1 jiekexu 192.168.75.32 jiekexu复制
8、恢复控制文件
rman target / restore controlfile from '/tmp/sk_backup/jieke/full_controlfile_lqv0rlil_1_1'; jiekxu1:/tmp/sk_backup/jieke$rman target / Recovery Manager: Release 11.2.0.4.0 - Production on Sun May 24 14:47:50 2020 Copyright (c) 1982, 2011, Oracle and/or its affiliates. All rights reserved. connected to target database: jiekexu (not mounted) RMAN> restore controlfile from '/tmp/sk_backup/jieke/full_controlfile_lqv0rlil_1_1'; Starting restore at 2020-05-24 14:49:56 using target database control file instead of recovery catalog allocated channel: ORA_DISK_1 channel ORA_DISK_1: SID=1893 device type=DISK channel ORA_DISK_1: restoring control file channel ORA_DISK_1: restore complete, elapsed time: 00:00:01 output file name=/oradata/jiekexu/controlfile/current01.ctl Finished restore at 2020-05-24 14:49:57复制
9、启动数据库至 mount 状态
sql'alter database mount'; RMAN> sql'alter database mount'; sql statement: alter database mount released channel: ORA_DISK_1 RMAN>复制
10、生成修改路径的语句
原库执行（生成替换数据文件的语句）：
set pagesize 200 linesize 200 select 'set newname for datafile ' || a.FILE# || ' to "' || a.NAME || '";' from v$datafile a union all select 'set newname for tempfile ' || a.FILE# || ' to "' || a.NAME || '";' from v$tempfile a union all SELECT 'SQL "ALTER DATABASE RENAME FILE ''''' || a.MEMBER || ''''' to ''''' || a.MEMBER || ''''' ";' FROM v$logfile a;复制
将查询出来的结果做相应替换
set newname for datafile 1 to "+DATA/jiekexu/datafile/system.256.990206091"; set newname for datafile 2 to "+DATA/jiekexu/datafile/sysaux.257.990206091"; set newname for datafile 3 to "+DATA/jiekexu/datafile/undotbs1.258.990206091"; set newname for datafile 4 to "+DATA/jiekexu/datafile/users.259.990206091"; set newname for datafile 5 to "+DATA/jiekexu/datafile/undotbs2.264.990206217"; set newname for datafile 6 to "+DATA/jiekexu/datafile/jiekeusr.268.990531275"; set newname for datafile 7 to "+DATA/jiekexu/datafile/jiekeusr.269.990531399"; set newname for datafile 8 to "+DATA/jiekexu/datafile/jiekeusr.270.990531567"; set newname for tempfile 1 to "+DATA/jiekexu/tempfile/temp.263.990206169"; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_2.262.990206165'' to ''+DATA/jiekexu/onlinelog/group_2.262.990206165'' "; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_1.261.990206165'' to ''+DATA/jiekexu/onlinelog/group_1.261.990206165'' "; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_3.265.990206285'' to ''+DATA/jiekexu/onlinelog/group_3.265.990206285'' "; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_4.266.990206285'' to ''+DATA/jiekexu/onlinelog/group_4.266.990206285'' ";复制
11、目标库恢复
备库创建数据文件目录：
mkdir -p /oradata/jiekexu/datafile mkdir -p /oradata/jiekexu/tempfile mkdir -p /oradata/jiekexu/onlinelog复制
rman 进行恢复
rman target / run{ set newname for datafile 1 to "/oradata/jiekexu/datafile/system.256.990206091"; set newname for datafile 2 to "/oradata/jiekexu/datafile/sysaux.257.990206091"; set newname for datafile 3 to "/oradata/jiekexu/datafile/undotbs1.258.990206091"; set newname for datafile 4 to "/oradata/jiekexu/datafile/users.259.990206091"; set newname for datafile 5 to "/oradata/jiekexu/datafile/undotbs2.264.990206217"; set newname for datafile 6 to "/oradata/jiekexu/datafile/jiekeusr.268.990531275"; set newname for datafile 7 to "/oradata/jiekexu/datafile/jiekeusr.269.990531399"; set newname for datafile 8 to "/oradata/jiekexu/datafile/jiekeusr.270.990531567"; set newname for tempfile 1 to "/oradata/jiekexu/tempfile/temp.263.990206169"; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_2.262.990206165'' to ''/oradata/jiekexu/onlinelog/group_2.262.990206165'' "; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_1.261.990206165'' to ''/oradata/jiekexu/onlinelog/group_1.261.990206165'' "; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_3.265.990206285'' to ''/oradata/jiekexu/onlinelog/group_3.265.990206285'' "; SQL "ALTER DATABASE RENAME FILE ''+DATA/jiekexu/onlinelog/group_4.266.990206285'' to ''/oradata/jiekexu/onlinelog/group_4.266.990206285'' "; restore database; switch datafile all; switch tempfile all; }复制
恢复归档
查看归档进程号
list backupset of archivelog all;复制
恢复完数据文件后，直接 list backupset of archivelog all;
找到最新的归档号进行恢复
恢复归档：
run{ set until sequence 3219 thread 1; set until sequence 3219 thread 2; recover database; } List of Archived Logs in backup set 6830 Thrd Seq Low SCN Low Time Next SCN Next Time ---- ------- ---------- ------------------- ---------- --------- 1 3202 67048837 2020-05-21 17:58:09 67086372 2020-05-21 23:58:10 1 3203 67086372 2020-05-21 23:58:10 67105740 2020-05-22 04:39:05 1 3204 67105740 2020-05-22 04:39:05 67105758 2020-05-22 04:39:10 1 3205 67105758 2020-05-22 04:39:10 67110100 2020-05-22 05:58:11 1 3206 67110100 2020-05-22 05:58:11 67139583 2020-05-22 11:58:10 1 3207 67139583 2020-05-22 11:58:10 67160819 2020-05-22 16:49:57 1 3208 67160819 2020-05-22 16:49:57 67160828 2020-05-22 16:50:00 1 3209 67160828 2020-05-22 16:50:00 67160858 2020-05-22 16:50:12 1 3210 67160858 2020-05-22 16:50:12 67160866 2020-05-22 16:50:15 2 3211 67048841 2020-05-21 17:58:10 67086375 2020-05-21 23:58:11 2 3212 67086375 2020-05-21 23:58:11 67105736 2020-05-22 04:39:04 2 3213 67105736 2020-05-22 04:39:04 67105763 2020-05-22 04:39:13 2 3214 67105763 2020-05-22 04:39:13 67110097 2020-05-22 05:58:11 2 3215 67110097 2020-05-22 05:58:11 67139587 2020-05-22 11:58:12 2 3216 67139587 2020-05-22 11:58:12 67160815 2020-05-22 16:49:57 2 3217 67160815 2020-05-22 16:49:57 67160843 2020-05-22 16:50:06 2 3218 67160843 2020-05-22 16:50:06 67160854 2020-05-22 16:50:12 2 3219 67160854 2020-05-22 16:50:12 67160870 2020-05-22 16:50:18复制
resetlogs 打开数据库
alter database open resetlogs;复制
12、恢复后的清理操作
删除未使用的 redo
col instance format a8 select thread#,instance,status,enabled from v$thread; select group#,thread#,archived,status from v$log; -- 禁用线程 2 alter database disable thread 2; SQL> select member from v$logfile; MEMBER -------------------------------------------------------------------------------- /oradata/jiekexu/onlinelog/group_2.262.990206165 /oradata/jiekexu/onlinelog/group_1.261.990206165 /oradata/jiekexu/onlinelog/o1_mf_3_hdnrcfoy_.log /oradata/jiekexu/onlinelog/o1_mf_4_hdnrdk70_.log SQL> select group#,thread#,archived,status,bytes/1024/1024 from v$log; GROUP# THREAD# ARC STATUS BYTES/1024/1024 ---------- ---------- --- ---------------- --------------- 1 1 NO CURRENT 200 2 1 YES INACTIVE 200 3 1 YES INACTIVE 200 4 1 YES UNUSED 200 SQL> alter database drop logfile group 3; Database altered. SQL> alter database drop logfile group 4; --重新添加第 3、4 组日志 alter database add logfile ('/oradata/jiekexu/onlinelog/group_3.263.dbf') size 200M ; alter database add logfile ('/oradata/jiekexu/onlinelog/group_4.264.dbf') size 200M ; SQL> select group#,thread#,archived,status ,bytes/1024/1024 from v$log; GROUP# THREAD# ARC STATUS BYTES/1024/1024 ---------- ---------- --- ---------------- --------------- 1 1 YES INACTIVE 200 2 1 YES INACTIVE 200 3 1 NO CURRENT 200 4 1 YES INACTIVE 200 SQL> SQL> select member from v$logfile; MEMBER -------------------------------------------------------------------------------- /oradata/jiekexu/onlinelog/group_2.262.990206165 /oradata/jiekexu/onlinelog/group_1.261.990206165 /oradata/jiekexu/onlinelog/group_3.263.dbf /oradata/jiekexu/onlinelog/group_4.264.dbf复制
清除多余的 undo
select name from v$tablespace where name like 'UNDO%'; show parameter undo_tablespace; drop tablespace undotbs2 including contents and datafiles;复制
添加 redo 日志组
SQL> select bytes/1024/1024 from v$log; BYTES/1024/1024 --------------- 200 200 200 200 ----- 添加日志组 SQL> alter database add logfile THREAD 1 group 5 size 200M ; Database altered. SQL> select bytes/1024/1024 from v$log; BYTES/1024/1024 --------------- 200 200 200 200 200 SQL> select group#,thread#,archived,status, bytes/1024/1024 from v$log; GROUP# THREAD# ARC STATUS ---------- ---------- --- ---------------- 1 1 NO CURRENT 2 1 YES UNUSED 3 2 YES INACTIVE 4 2 YES UNUSED 5 1 YES UNUSED SQL> select group#,thread#,archived,status,bytes/1024/1024,FIRST_CHANGE#,FIRST_TIME from v$log; GROUP# THREAD# ARC STATUS BYTES/1024/1024 ---------- ---------- --- ---------------- --------------- 1 1 NO CURRENT 200 2 1 YES UNUSED 200 3 2 YES INACTIVE 200 4 2 YES UNUSED 200 5 1 YES UNUSED 200 -- 如果为非正在应用的 active 状态 standby 日志组，先 clear，再删除重建 select group#,thread#,status,bytes/1024/1024 from v$standby_log order by thread#; GROUP# THREAD# STATUS ---------- ---------- ---------- 5 1 UNASSIGNED 6 1 UNASSIGNED 7 1 UNASSIGNED 8 2 UNASSIGNED 9 2 UNASSIGNED 10 2 UNASSIGNED alter database clear logfile group 8; alter database drop standby logfile group 8; alter database add logfile THREAD 1 group 3 size 200M ; ---节点1 添加一组日志 alter database clear logfile group 3; --删除节点 2 日志组 alter database drop logfile group 3; SQL> alter database clear logfile group 3; Database altered. SQL> alter database clear logfile group 4; Database altered. SQL> alter database drop logfile group 3; Database altered. SQL> alter database drop logfile group 4; Database altered.复制
13、验证数据库
重启数据库验证：
shutdown immediate; startup;复制
14、配置监听和 TNS
手动配置监听
vi $ORACLE_HOME/network/admin/listener.ora LISTENER= (DESCRIPTION= (ADDRESS_LIST= (ADDRESS=(PROTOCOL=tcp)(HOST=jiekexu1)(PORT=1521)) (ADDRESS=(PROTOCOL=ipc)(KEY=extproc)))) SID_LIST_LISTENER = (SID_LIST = (SID_DESC = (SID_NAME = PLSExtProc) (ORACLE_HOME = /app/product/11.2.0/db) (PROGRAM = extproc) ) (SID_DESC = (GLOBAL_DBNAME = jiekexu1) (ORACLE_HOME = /app/product/11.2.0/db) (SID_NAME = jiekexu1) ) )复制
启动监听
lsnrctl start复制
手动配置 tns
jiekexu1 = (DESCRIPTION = (ADDRESS_LIST = (ADDRESS = (PROTOCOL = TCP)(HOST = jiekexu1)(PORT = 1521)) ) (CONNECT_DATA = (SERVICE_NAME = jiekexu1) ) )复制
15、设置删除归档策略
vi clear_arch.sh #!/bin/ksh #export ORACLE_SID=test rman target / log=/home/oracle/clear_arch.log<<EOF ## delete noprompt force archivelog all completed before 'sysdate-3'; delete noprompt archivelog all completed before 'sysdate-5'; exit EOF复制
chmod +x clear_arch.sh复制
root 用户设置
crontab -e 22 2 * * * su - oracle -c /home/oracle/clear_arch.sh复制
查看定时任务
crontab -l复制
执行验证
su - oracle -c /home/oracle/clear_arch.sh cat /home/oracle/clear_arch.log复制
全文完，希望可以帮到正在阅读的你，如果觉得有帮助，可以分享给你身边的朋友，同事，你关心谁就分享给谁，一起学习共同进步~~~
