部署Kubernetes的dashboard

# Copyright 2017 The Kubernetes Authors.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
#     http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.


# ------------------- Dashboard Secret ------------------- #


apiVersion: v1
kind: Secret
metadata:
  labels:
    k8s-app: kubernetes-dashboard
  name: kubernetes-dashboard-certs
  namespace: kube-system
type: Opaque


---
# ------------------- Dashboard Service Account ------------------- #


apiVersion: v1
kind: ServiceAccount
metadata:
  labels:
    k8s-app: kubernetes-dashboard
  name: kubernetes-dashboard
  namespace: kube-system


---
# ------------------- Dashboard Role & Role Binding ------------------- #


kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: kubernetes-dashboard-minimal
  namespace: kube-system
rules:
  # Allow Dashboard to create 'kubernetes-dashboard-key-holder' secret.
- apiGroups: [""]
  resources: ["secrets"]
  verbs: ["create"]
  # Allow Dashboard to create 'kubernetes-dashboard-settings' config map.
- apiGroups: [""]
  resources: ["configmaps"]
  verbs: ["create"]
  # Allow Dashboard to get, update and delete Dashboard exclusive secrets.
- apiGroups: [""]
  resources: ["secrets"]
  resourceNames: ["kubernetes-dashboard-key-holder", "kubernetes-dashboard-certs"]
  verbs: ["get", "update", "delete"]
  # Allow Dashboard to get and update 'kubernetes-dashboard-settings' config map.
- apiGroups: [""]
  resources: ["configmaps"]
  resourceNames: ["kubernetes-dashboard-settings"]
  verbs: ["get", "update"]
  # Allow Dashboard to get metrics from heapster.
- apiGroups: [""]
  resources: ["services"]
  resourceNames: ["heapster"]
  verbs: ["proxy"]
- apiGroups: [""]
  resources: ["services/proxy"]
  resourceNames: ["heapster", "http:heapster:", "https:heapster:"]
  verbs: ["get"]


---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: kubernetes-dashboard-minimal
  namespace: kube-system
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: kubernetes-dashboard-minimal
subjects:
- kind: ServiceAccount
  name: kubernetes-dashboard
  namespace: kube-system


---
# ------------------- Dashboard Deployment ------------------- #


kind: Deployment
apiVersion: apps/v1beta2
metadata:
  labels:
    k8s-app: kubernetes-dashboard
  name: kubernetes-dashboard
  namespace: kube-system
spec:
  replicas: 1
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      k8s-app: kubernetes-dashboard
  template:
    metadata:
      labels:
        k8s-app: kubernetes-dashboard
    spec:
      containers:
      - name: kubernetes-dashboard
        #image: k8s.gcr.io/kubernetes-dashboard-amd64:v1.8.3
        #image: mirrorgooglecontainers/kubernetes-dashboard-amd64:v1.10.1
        image: registry-vpc.cn-hangzhou.aliyuncs.com/xmk8s/kubernetes-dashboard-amd64:v1.10.1
        ports:
        - containerPort: 8443
          protocol: TCP
        args:
          - --auto-generate-certificates
          - --token-ttl=0
          # Uncomment the following line to manually specify Kubernetes API server Host
          # If not specified, Dashboard will attempt to auto discover the API server and connect
          # to it. Uncomment only if the default does not work.
          # - --apiserver-host=http://my-address:port
        volumeMounts:
        - name: kubernetes-dashboard-certs
          mountPath: /certs
          # Create on-disk volume to store exec logs
        - mountPath: /tmp
          name: tmp-volume
        livenessProbe:
          httpGet:
            scheme: HTTPS
            path: /
            port: 8443
          initialDelaySeconds: 30
          timeoutSeconds: 30
      volumes:
      - name: kubernetes-dashboard-certs
        secret:
          secretName: kubernetes-dashboard-certs
      - name: tmp-volume
        emptyDir: {}
      serviceAccountName: kubernetes-dashboard
      # Comment the following tolerations if Dashboard must not be deployed on master
      tolerations:
      - key: node-role.kubernetes.io/master
        effect: NoSchedule


---
# ------------------- Dashboard Service ------------------- #


kind: Service
apiVersion: v1
metadata:
  labels:
    k8s-app: kubernetes-dashboard
    kubernetes.io/cluster-service: "true"
    addonmanager.kubernetes.io/mode: Reconcile
  name: kubernetes-dashboard
  namespace: kube-system
spec:
  ports:
    - port: 443
      targetPort: 8443
  selector:
    k8s-app: kubernetes-dashboard
  type: NodePort
复制

kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: ui-admin
rules:
- apiGroups:
  - ""
  resources:
  - services
  - services/proxy
  verbs:
  - '*'


---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: ui-admin-binding
  namespace: kube-system
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: ui-admin
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: User
  name: admin
复制

apiVersion: v1
kind: ServiceAccount
metadata:
  name: admin-user
  namespace: kube-system


---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: admin-user
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: admin-user
  namespace: kube-system


复制

apiVersion: v1
kind: Service
metadata:
  name: dashboard-ui
  namespace: kube-system
spec:
  selector:
    k8s-app: kubernetes-dashboard
  ports:
  - name: web
    port: 443
    targetPort: 8443
---
apiVersion: extensions/v1beta1
kind: Ingress
metadata:
  name: dashboard-ui
  namespace: kube-system
  annotations:
    kubernetes.io/ingress.class: nginx
    certmanager.k8s.io/issuer: "letsencrypt-prod"
    certmanager.k8s.io/acme-challenge-type: http01
    ingress.kubernetes.io/ssl-passthrough: "true"
    nginx.org/ssl-backends: "kubernetes-dashboard"
    kubernetes.io/ingress.allow-http: "false"
    nginx.ingress.kubernetes.io/secure-backends: "true"
    nginx.ingress.kubernetes.io/backend-protocol: "HTTPS"
    #nginx.ingress.kubernetes.io/whitelist-source-range:
spec:
  tls:
  - hosts:
    - <xxxxxx>
    secretName: <xxxxxx>
  rules:
  - host: <xxxxxx>
    http:
      paths:
      - path: /
        backend:
          serviceName: kubernetes-dashboard
          servicePort: 443
复制

apiVersion: v1
kind: ServiceAccount
metadata:
  name: dashboard-read-user
  namespace: kube-system


---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: dashboard-read-binding
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: dashboard-read-clusterrole
subjects:
- kind: ServiceAccount
  name: dashboard-read-user
  namespace: kube-system


---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: dashboard-read-clusterrole
rules:
- apiGroups:
  - ""
  resources:
  - configmaps
  - endpoints
  - persistentvolumeclaims
  - pods
  - replicationcontrollers
  - replicationcontrollers/scale
  - serviceaccounts
  - services
  - nodes
  - persistentvolumeclaims
  - persistentvolumes
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - ""
  resources:
  - bindings
  - events
  - limitranges
  - namespaces/status
  - pods/log
  - pods/status
  - replicationcontrollers/status
  - resourcequotas
  - resourcequotas/status
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - ""
  resources:
  - namespaces
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - apps
  resources:
  - daemonsets
  - deployments
  - deployments/scale
  - replicasets
  - replicasets/scale
  - statefulsets
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - autoscaling
  resources:
  - horizontalpodautoscalers
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - batch
  resources:
  - cronjobs
  - jobs
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - extensions
  resources:
  - daemonsets
  - deployments
  - deployments/scale
  - ingresses
  - networkpolicies
  - replicasets
  - replicasets/scale
  - replicationcontrollers/scale
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - policy
  resources:
  - poddisruptionbudgets
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - networking.k8s.io
  resources:
  - networkpolicies
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - storage.k8s.io
  resources:
  - storageclasses
  - volumeattachments
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - rbac.authorization.k8s.io
  resources:
  - clusterrolebindings
  - clusterroles
  - roles
  - rolebindings
  verbs:
  - get
  - list
  - watch
复制

kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: ui-read
rules:
- apiGroups:
  - ""
  resources:
  - services
  - services/proxy
  verbs:
  - get
  - list
  - watch


---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: ui-read-binding
  namespace: kube-system
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: ui-read
subjects:
- apiGroup: rbac.authorization.k8s.io
  kind: User
  name: readonly
复制

kubectl apply -f .
复制

kubectl describe  -n kube-system secrets admin-user-token-<这里是一个hash值>
复制

kubectl describe  -n kube-system secrets dashboard-read-user-token-<这里是一个hash值>
复制
