第 21 章 Apache Sqoop

21.1. 安装 Sqoop
21.2. sqoop2-tool

21.2.1. verify
21.2.2. upgrade

21.3. sqoop2-shell

21.3.6.1. link
21.3.5.1. create job
21.3.5.2. show job
21.3.5.3. start job
21.3.5.4. status job
21.3.4.1. hdfs-connector
21.3.4.2. generic-jdbc-connector
21.3.2.1. server
21.3.2.2. 要设置可查看具体出错信息
21.3.1. show version
21.3.2. set
21.3.3. show connector
21.3.4. link
21.3.5. job
21.3.6. update

21.4. FAQ

21.4.1. Unable to load native-hadoop library for your platform

21.1. 安装 Sqoop

OSCM 一键安装

curl -s https://raw.githubusercontent.com/oscm/shell/master/database/apache-sqoop/sqoop-1.99.7-bin-hadoop200.sh | bash		复制

		复制

启动 Sqoop

/srv/apache-sqoop/bin/sqoop.sh server start		复制

检查 Sqoop 线程

		[hadoop@netkiller ~]$ jps
2512 SecondaryNameNode
23729 SqoopJettyServer
2290 DataNode
871 ResourceManager
23885 Jps复制

21.2. sqoop2-tool

21.2.1. verify 配置文件检验工具

[hadoop@iZj6ciilv2rcpgauqg2uuwZ ~]$ sqoop2-tool verify
Setting conf dir: /srv/apache-sqoop/bin/../conf
Sqoop home directory: /srv/apache-sqoop
Sqoop tool executor:
	Version: 1.99.7
	Revision: 435d5e61b922a32d7bce567fe5fb1a9c0d9b1bbb
	Compiled on Tue Jul 19 16:08:27 PDT 2016 by abefine
Running tool: class org.apache.sqoop.tools.tool.VerifyTool
0    [main] INFO  org.apache.sqoop.core.SqoopServer  - Initializing Sqoop server.
6    [main] INFO  org.apache.sqoop.core.PropertiesConfigurationProvider  - Starting config file poller thread
Verification was successful.
Tool class org.apache.sqoop.tools.tool.VerifyTool has finished correctly.
			复制

21.3. sqoop2-shell

进入 sqoop2-shell

		[hadoop@netkiller ~]$ sqoop2-shell
Setting conf dir: /srv/apache-sqoop/bin/../conf
Sqoop home directory: /srv/apache-sqoop
Sqoop Shell: Type 'help' or '\h' for help.
sqoop:000>
		复制

Sqoop client script:

		sqoop2-shell /path/to/your/script.sqoop
		复制

21.3.1. show version

			sqoop:000> show version
client version:
  Sqoop 1.99.7 source revision 435d5e61b922a32d7bce567fe5fb1a9c0d9b1bbb
  Compiled by abefine on Tue Jul 19 16:08:27 PDT 2016
			复制

			sqoop:000> show version --all
client version:
  Sqoop 1.99.7 source revision 435d5e61b922a32d7bce567fe5fb1a9c0d9b1bbb
  Compiled by abefine on Tue Jul 19 16:08:27 PDT 2016
0    [main] WARN  org.apache.hadoop.util.NativeCodeLoader  - Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
server version:
  Sqoop 1.99.7 source revision 435d5e61b922a32d7bce567fe5fb1a9c0d9b1bbb
  Compiled by abefine on Tue Jul 19 16:08:27 PDT 2016
API versions:
  [v1]
			复制

21.3.2. set

21.3.2.1. server

				sqoop:000> set server --host master --port 12000 --webapp sqoop
Server is set successfully
				复制

21.3.2.2. 要设置可查看具体出错信息

				sqoop:000> set option --name verbose --value true
Verbose option was changed to true
				复制

21.3.3. show connector

sqoop:000> show connector
0    [main] WARN  org.apache.hadoop.util.NativeCodeLoader  - Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
+------------------------+---------+------------------------------------------------------------+----------------------+
|          Name          | Version |                           Class                            | Supported Directions |
+------------------------+---------+------------------------------------------------------------+----------------------+
| generic-jdbc-connector | 1.99.7  | org.apache.sqoop.connector.jdbc.GenericJdbcConnector       | FROM/TO              |
| kite-connector         | 1.99.7  | org.apache.sqoop.connector.kite.KiteConnector              | FROM/TO              |
| oracle-jdbc-connector  | 1.99.7  | org.apache.sqoop.connector.jdbc.oracle.OracleJdbcConnector | FROM/TO              |
| ftp-connector          | 1.99.7  | org.apache.sqoop.connector.ftp.FtpConnector                | TO                   |
| hdfs-connector         | 1.99.7  | org.apache.sqoop.connector.hdfs.HdfsConnector              | FROM/TO              |
| kafka-connector        | 1.99.7  | org.apache.sqoop.connector.kafka.KafkaConnector            | TO                   |
| sftp-connector         | 1.99.7  | org.apache.sqoop.connector.sftp.SftpConnector              | TO                   |
+------------------------+---------+------------------------------------------------------------+----------------------+
sqoop:000>
sqoop list-databases --connect  jdbc:mysql://192.168.1.1:3306/ --username root --password 123456			复制

			sqoop:000> show connector --all
复制

21.3.4. link

21.3.4.1. hdfs-connector

				sqoop:000> create link -connector hdfs-connector
0    [main] WARN  org.apache.hadoop.util.NativeCodeLoader  - Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
Creating link for connector with name hdfs-connector
Please fill following values to create new link object
Name: hdfs
HDFS cluster
URI: hdfs://127.0.0.1:9000
Conf directory:
Additional configs::
There are currently 0 values in the map:
entry#
New link was successfully created with validation status OK and name hdfs
sqoop:000>
				复制

				sqoop:000> show link
+------+----------------+---------+
| Name | Connector Name | Enabled |
+------+----------------+---------+
| hdfs | hdfs-connector | true    |
+------+----------------+---------+
				复制

21.3.4.2. generic-jdbc-connector

				sqoop:000> create link -connector generic-jdbc-connector
Creating link for connector with name generic-jdbc-connector
Please fill following values to create new link object
Name: mysql
Database connection
Driver class: com.mysql.jdbc.Driver
Connection String: jdbc:mysql://127.0.0.1:3306/test
Username: test
Password: ****
Fetch Size:
Connection Properties:
There are currently 0 values in the map:
entry#
SQL Dialect
Identifier enclose:
New link was successfully created with validation status OK and name mysql
				复制

				sqoop:000> show link
+-------+------------------------+---------+
| Name  |     Connector Name     | Enabled |
+-------+------------------------+---------+
| mysql | generic-jdbc-connector | true    |
| hdfs  | hdfs-connector         | true    |
+-------+------------------------+---------+
				复制

21.3.5. job

21.3.5.1. create job

				sqoop:000> create job -f "mysql" -t "hdfs"
Creating job for links with from name mysql and to name hdfs
Please fill following values to create new job object
Name: from-mysql-to-hdfs
Database source
Schema name: test
Table name: member
SQL statement:
Column names:
There are currently 0 values in the list:
element#
Partition column:
Partition column nullable:
Boundary query:
Incremental read
Check column:
Last value:
Target configuration
Override null value:
Null value:
File format:
  0 : TEXT_FILE
  1 : SEQUENCE_FILE
  2 : PARQUET_FILE
Choose: 0
Compression codec:
  0 : NONE
  1 : DEFAULT
  2 : DEFLATE
  3 : GZIP
  4 : BZIP2
  5 : LZO
  6 : LZ4
  7 : SNAPPY
  8 : CUSTOM
Choose: 0
Custom codec:
Output directory: /sqoop/member
Append mode:
Throttling resources
Extractors:
Loaders:
Classpath configuration
Extra mapper jars:
There are currently 0 values in the list:
element#
New job was successfully created with validation status OK  and name from-mysql-to-hdfs
				复制

21.3.5.2. show job

				sqoop:000> show job
+----+--------------------+--------------------------------+-----------------------+---------+
| Id |        Name        |         From Connector         |     To Connector      | Enabled |
+----+--------------------+--------------------------------+-----------------------+---------+
| 1  | from-mysql-to-hdfs | mysql (generic-jdbc-connector) | hdfs (hdfs-connector) | true    |
+----+--------------------+--------------------------------+-----------------------+---------+
				复制

21.3.5.3. start job

				sqoop:000> start job -n from-mysql-to-hdfs
sqoop:000> start job -n from-mysql-to-hdfs
Submission details
Job Name: from-mysql-to-hdfs
Server URL: http://localhost:12000/sqoop/
Created by: hadoop
Creation date: 2017-07-22 23:18:02 CST
Lastly updated by: hadoop
External ID: job_1499236611045_0001
	http://iZj6ciilv2rcpgauqg2uuwZ:8088/proxy/application_1499236611045_0001/
2017-07-22 23:18:02 CST: BOOTING  - Progress is not available
				复制

启动后进入HDFS查看导入情况

				[hadoop@netkiller ~]$ hdfs dfs -ls /sqoop
[hadoop@netkiller ~]$ hdfs dfs -ls /member
Found 10 items
-rw-r--r--   3 hadoop supergroup          0 2017-07-22 23:18 /member/310af608-5533-4bc2-bfb8-eaa45470b04d.txt
-rw-r--r--   3 hadoop supergroup         48 2017-07-22 23:18 /member/36bc39a5-bc73-4065-a361-ff2d61c4922c.txt
-rw-r--r--   3 hadoop supergroup          0 2017-07-22 23:18 /member/3e855400-84a9-422d-b50c-1baa9666a719.txt
-rw-r--r--   3 hadoop supergroup        140 2017-07-22 23:18 /member/3e8dad92-e0f1-4a74-a337-642cf4e6d634.txt
-rw-r--r--   3 hadoop supergroup         55 2017-07-22 23:18 /member/4a9f47f1-0413-4149-a93a-ed8b51efbc87.txt
-rw-r--r--   3 hadoop supergroup          0 2017-07-22 23:18 /member/4dc5bfe7-1cd9-4d9b-96a8-07e82ed79a71.txt
-rw-r--r--   3 hadoop supergroup          0 2017-07-22 23:18 /member/60dbcc60-61f2-4433-af39-1dfdfc048940.txt
-rw-r--r--   3 hadoop supergroup          0 2017-07-22 23:18 /member/6d02ed89-94d9-4d4b-87ed-d5da9d2bf9fe.txt
-rw-r--r--   3 hadoop supergroup        209 2017-07-22 23:18 /member/cf7b7185-3ab6-4077-943a-26228b769c57.txt
-rw-r--r--   3 hadoop supergroup          0 2017-07-22 23:18 /member/f2e0780d-ad33-4b35-a1c7-b3fbc23e303d.txt
				复制

21.3.5.4. status job

				sqoop:000> status job -n from-mysql-to-hdfs
				复制

21.3.6. update

21.3.6.1. link

				sqoop:000> update link -n  mysql
Updating link with name mysql
Please update link:
Name: mysql
Database connection
Driver class: com.mysql.jdbc.Driver
Connection String: jdbc:mysql://127.0.0.1:3306/test
Username: test
Password: ****
Fetch Size:
Connection Properties:
There are currently 0 values in the map:
entry#
SQL Dialect
Identifier enclose:
link was successfully updated with status OK
				复制
